Video - Raymarine G-Series system Installation & Commissioning Instructions

Video

Problem
Video picture is unavailable at some or all
Nav stations.
G-Series Installation & Commissioning
Possible cause / solution
• Video signal is not reaching the GVM400 video
module.
• GVM400 video module or power supply
problem.
hs
• SeaTalk network problem
• Software mismatch between equipment may
prevent communication.
96
Possible solutions
• Check the video source equipment.
• Check the video connections to the GVM400 unit.
• Check the GVM400 status.
See troubleshooting GVM400 LED indications on
page 100.
• Check the GVM400 power supply.
Refer to troubleshooting Power up on page
• Check that all GVM400 and all GPM400s are connected
hs
to the SeaTalk switch.
• Check the status of the SeaTalk
Refer to troubleshooting Status LEDs on page 98
hs
• Check that SeaTalk cables are free from damage.
• Contact Raymarine technical support
92.
hs
Switch.
