3.5 SeaTalk wireless basestation
Pack items
SeaTalk
wireless basestation
ng
SeaTalk backbone cable
ng
SeaTalk spur cable
Description
Wireless basestation
1 m (3.3 ft) SeaTalk NG spur cable - stripped ends
ng
400 mm (15.75 in) SeaTalk backbone cable
SeaTalk NG T-connector
Installation instructions
G-Series Installation & Commissioning
ng
SeaTalk T connector
Part No.
E02045
A06043
A06033
A06028
87086
3.6

Marine monitors

Pack items
Description
17" Marine Display
19" Marine Display
Sun cover
2 x mounting brackets
5 m (16.4 ft) VGA cable
1.5 m (4.9 ft) Power cable
28
Marine
display
Mounting brackets x 2
Sun cover
1.5 meter Power Cable
5 meter VGA cable assembly
Part No.
E02036
E02037
Part numbers
depend on the
display model.
Refer to your
display handbook
for details
