6.1

Power up test

It is advisable to perform an initial power-up test to help ensure that
the system is wired correctly.
Perform the following initial checks before proceeding to the com-
missioning stage:
Turn on breakers
Turn on the power to the equipment at the distribution panel:
1. Monitors and ancillary equipment.
2. GPM400 processors.
Power up sequence
Power up the monitors first to allow the boot sequence and start-up
information to be shown at master monitors.
Check system:
Wait for 2 minutes whilst the boot sequence is completed, then
check each of the following:
• Monitors
• Keyboards
• GPM400 processors
• GVM400 Video Modules
hs
• SeaTalk Switch
• DSM sounder module. (refer to separate instructions supplied
with the DSM)
Marine monitor checks
You will need to select the appropriate input on each monitor.
On a G-Series marine monitor:
• Press the power key (if required)
• Press the Left/Right arrow keys to scroll through the inputs.
G-Series Installation & Commissioning
On a healthy system all monitors will:
• show the G-Series set-up wizard screen on the appropriate in-
put channel.
Note: Only the master monitors will show the initial boot
sequence. The repeat monitors may not begin to operate
until the system has ran through its start-up sequence
(approximately 2 minutes after power on).
Keyboard checks
You can check that each keyboard is correctly connected by look-
ing at its LCD monitor.
On a healthy system all keyboards will:
• Display the message "NOT ASSIGNED".
GPM400 processor checks
Check that each GPM is correctly connected by looking at its LED
(found next to the SeaTalk/alarm output).
On a healthy GPM400:
• LED will flash Green.
For a full LED status listing see
GVM400 video processor checks
Check that each GPM is correctly connected by looking at its LED
(found next to the SeaTalk/alarm output).
On a healthy GVM400:
• LED will flash Green.
For a full LED status listing see
hs
SeaTalk switch
Use this to check the status of your SeaTalk
70
page 99.
page 100.
hs
network connections.
