Chapter 4: Cables and connections

This section contains details of cables and connections. Use it to plan your system wiring and ensure that you
have the necessary cables available.
Chapter contents
• 4.1 General instructions on page 32
• 4.2 Power distribution on page 33
• 4.3 GPM400 processor on page 37
• 4.4 Monitor connections on page 38
• 4.5 Keyboard connections on page 40
• 4.6 Video and Entertainment on page 43
hs
• 4.7 SeaTalk network on page 47
• 4.8 GPS Connection on page 49
• 4.9 SeaTalk & Alarm connection on page 50
• 4.10 NMEA 0183 connections on page 51
ng
• 4.11 SeaTalk connections on page 54
• 4.12 NMEA 2000 connections on page 55
