5.6
Alarm buzzer
The alarm is used to alert the operator to alarms and other audible
warnings.
38 mm
(1.5 in)
Mounting and environment
•
Mount below decks in a dry area
•
Install on a vertical surface.
•
Do NOT mount near sources of heat or vibration. (e.g. engine)
•
Install well away from potential sources of ignition.
18 mm
(0.7 in)
D10203-1
67
Chapter 5: Installation and mounting
