Screen resolution and aspect ratio
Each GPM will output the same screen resolution to all connected
displays.
Therefore where multiple displays are connected to a single GPM
they should have the same aspect ratio and screen resolution. For
example we recommend that wide screen televisions and standard
displays are connected to separate GPMs.
IP Address
When connecting a display to the processor, note its IP address on
your system diagram. You will need to refer to this during the com-
missioning process. (See Appendix B
Selector Switch
Raymarine G-Series displays have a selector switch located by the
hs
SeaTalk connector. This must be in the UP position for connec-
hs
tion to the SeaTalk network.
3rd party displays
Ensure that any 3rd party (non-Raymarine) displays have electrical
isolation between the video connections and power supply (and
any other 0 V referenced connection). This is to avoid 0 V loops
which can cause interference issues.
Marine display cables
The following cables can be used with marine displays:
Cable Part No
DVI Connection
5 m (16.4 ft) E06021
DVI to DVI (digital) cable
10 m (32.8 ft) E06022
DVI to DVI (digital) cable
for sample diagrams.)
Notes
To ensure optimum signal quality
use only Raymarine cables.
Cable Part No
VGA
500 mm (19.69 in) E06053
DVI-VGA converter
1.5 m (4.9 ft) R08130
VGA cable
5 m (16.4 ft) R08174
VGA cable
10 m (32.8 ft) R08296
VGA cable
20 m (65.6 ft) R08297
VGA cable
hs
Display to SeaTalk
1.5 m (4.9 ft) E55049
hs
SeaTalk cable
5 m (16.4 ft) E55050
hs
SeaTalk cable
10 m (32.8 ft) E55051
hs
SeaTalk cable
20 m (65.6 ft) E55052
hs
SeaTalk cable
Power
1.5 m (4.9 ft) R08173
Power cable
39
Notes
To ensure optimum signal quality
use only Raymarine cables.
Required for any VGA connec-
tion to the GPM400.
Supplied with Raymarine
G-Series Marine Displays.
Required for keyboard control of
display functions.
Supplied with product
Chapter 4: Cables and connections
