G-Series Keyboard
Pack items
ng
SeaTalk
T connector
ng
SeaTalk
backbone cable
ng
SeaTalk
spur cable
G-Series Installation & Commissioning
Handbook/
Documentation
Suncover
Command
center keyboard
Panel seal
Rear clamp
assembly
Stud (x4)
Finger
nut (x4)
Description
G-Series command center keyboard
Sun cover
ng
1 m (3.3 ft) SeaTalk
/NMEA2000 cable
ng
400 mm (15.75 in) SeaTalk
ng
SeaTalk
T-piece connector
Rear cover / mounting bracket
Screw pack
Installation sheet
Warranty booklet
26
Part No.
E02044
R08307
A06039
backbone cable
A06033
A06028
R08308
R08309
87084
80017
