Appendix B - Nav Station schematic

Plan the connections and arrangement of your core system. This information is required when commissioning.
Nav station information
Name
Bridge - Left
Location
Bridge
IP address (When on SeaTalk hs only)
10-2-0-14
Video connection (delete as appropriate)
DVI / VGA
hs
SeaTalk (delete as appropriate)
YES / NO
GPM400 processor
Serial Number
1006021
Location
Left (switch cupboard)
Master GPM (delete as appropriate)
YES / NO
Bridge nav
Nav station name
Display 1
Keyboard
1 2 3
ABC DEF
4 5 6
WPTS
GHI JKL MNO PAGE MENU
MOB
ENTER
7 8 9
PQRS TUV WXYZ ACTIVE DATA
.
0
DODGE STANDBY PILOT OK
SeaTalk ng
Serial number
Location
Nav station location
Display 2 (if applicable)
Serial number
02070016
Location
Bridge
CANCEL
Wireless (delete as appropriate)
YES / NO
hs
SeaTalk switch
109
Bridge
Name
Bridge - Right
Location
Bridge
IP address (When on SeaTalk hs only)
10-2-0-2
Video connection (delete as appropriate)
DVI / VGA
hs
SeaTalk (delete as appropriate)
YES / NO
GPM400 processor
Serial number
1006024
Location
Right (switch cupboard)
Master GPM (delete as appropriate)
YES / NO
D10029-1
