Raymarine G-Series system Installation & Commissioning Instructions page 101

Color Operation
Warnings and Errors
Off Off < 2 minutes
Off for > 2minutes
Amber On steady
Amber Flashing x 1
Amber Flashing x 2
Amber Flashing x 3
Amber Flashing x 8
Amber/Red Alternating 750/250 ms
Red Flashing x 1
Red Flashing x 3
Red Flashing x 4
Red Flashing x 5
Red Flashing x 8
(May be followed by Flashing amber)
Causes
• Startup
• No power
•
• Power on
• Lamp test
• Input transducer
• No network / cable unplugged
• Over temperature warning
• Watchdog restart
• Software upgrade. This condition remains until a valid application is available
from Flash
• Voltage error
• Over temperature error
• Flash write error
• No application programmed
• Hardware read failure
101 Chapter 9: Troubleshooting
