Operation

Using the Digital Capture Unit consists of 4 major
operations, all of which can be done using the remote
control. These operations are grabbing images,
viewing images, printing images, and saving images to
CD-R disc. For details about remote control
operations, refer to the RM-P110 User's Guide.

Grabbing Images

To capture images from a video device using the RM-
P110 Remote Control Unit, use the following
procedure. (If you are using a custom-made device to
control the UPA-P100MD, the procedure to grab
images depends on your control device.)
Note
• Before you begin using the device as described
below, please make sure that a video device is
properly connected to the UPA-P100MD and turned
on. The connection procedure depends on your video
device.
• If you are using a digital video printer (UPA-D50 or
UPA-D70XR), also make sure that it is properly
connected and turned on.
1
Turn on the Digital Capture Unit. After
approximately 1 minute, you hear 3 beeps and
[Enter Patients name] appears on the remote
control display.
Enter Patients name:
Note
• Note that if you have cleared the [Remote Control
Unit Support] check box in the configuration
screen, the system assigns patient, doctor, and
procedure names automatically.
• If you press [ENT] without typing a patient's
name, the system assigns a name to the patient
automatically.
• If [Video Printer Support] is selected in the UPA-
P100MD configuration screen and if there is no
printer connected or it is off, the message [Error
opening SCSI card or printer off or printer SCSI
ID not 1] appears on the display before the screen
above appears.
2
Using the remote control keyboard, enter the
patient's name. The patient's name has a maximum
length of 18 alphanumerical characters. Press
[ENT]. [Enter Doctors name] appears.
Enter Doctors name:
3
Using the remote control keyboard, enter the name
of the doctor performing the procedure. The
doctor's name has a maximum length of 18
alphanumerical characters. Press [ENT]. [Enter
Procedure name] appears.
Enter Procedure name
Note
• Note that if you press [ENT] without entering any
information, the system assigns the name
"Doctor" to the user. Also, if you have selected
[Never ask] in the configuration screen, this
information does not appear and the system goes
directly to the next item.
• Also note that if you specify a default doctor
name and select [Use default] in the configuration
screen, the default name appears, allowing you to
modify it if necessary. If you do not need to
modify the name, simply press the [ENT] key to
proceed. See "The Configuration Screen" for
details.
4
Using the remote control keyboard, enter the name
of the procedure being performed. The procedure
name has a maximum length of 10 alphanumerical
characters. Press [ENT]. The function screen
appears on the remote control display.
Patient
1-Grab 2-Print
3-Burn 0-Exit
Tue Jul 31 17:30
Note
• If there is no video device connected to the UPA-
P100MD, the [No video present] message appears
on the display of the remote control. You are
unable to use the UPA-P100MD until a video
device is properly connected and turned on.
• Note that if you press [ENT] without entering any
information, the system assigns the name
"Procedure" to the current procedure. However, if
you have selected [Never ask] in the
configuration screen, this screen does not appear
and the system goes directly to the next screen.
19
