Simrad AP50 Autopilot

4.2 Settings Menu

SETTINGS

STEERING

THRUSTER
No
Yes
Note !
SETTINGS

W Init rudder

Midship

W Autotrim

Yes

Autotrim

48sec
Course adj. 1°
Compass diff. 10°
Off heading lim 10°
Drive engage Byp/clutch
Drive type Motor
Drive out 62%
Note !
78
Select SETTINGS in the Installation Menu by pressing the
(STBD) button and confirm this by rotating the course knob
clockwise.
Two groups of settings are available; Steering and Thruster
(only when thruster is installed).
If a thruster is not installed, the Steering menu appears when
entering the Settings menu.
Use the (PORT) or
menu items. Turn the course knob clockwise or counter
clockwise to adjust the values.
Steering
Select STEERING by pressing the
confirm this by rotating the course knob.
W Init rudder
Select between Midship or Actual rudder position in Work
mode.
When "Midship" is selected, the autopilot will use zero degrees
as the midship reference. Hence, the rudder will always move
to midship when switching from STANDBY or DODGE mode
to AUTO-WORK or NAV-WORK mode.
When "Actual" is selected, the autopilot will use the current
rudder position as the midship reference (bumpless transfer)
when switching from STANDBY or DODGE mode to AUTO-
WORK, or NAV-WORK.
"Midship" will always be used when switching to AUTO or
NAV from STBY/NFU/FU.
W Autotrim
Rotate the course knob to turn the Autotrim function off or on
in the AUTO-WORK and NAV-WORK modes.
Autotrim
When the vessel has a constant heading error due to external
forces such as wind and current, the Autotrim function corrects
for this by building up a constant rudder offset.
The value for the Autotrim parameter is the time it is allowed to
calculate the rudder offset.
(STBD) buttons to move through the
(STBD) button and
20222469 / B
