Simrad AP50 Autopilot
Set-up item
(abbrev. name)
FLUX1
RC25
FLUX2
RC25
WIND
DEPTH
LOG
60
Equipment
connected
(use one available from list)
(name)
Not connected
Connection to Robnet
Junction unit: HS+, HS–
J50, Power PCB NMEA I/P RX2+,RX2–
NI300X, NMEA port #1
NI300X, NMEA port #2
NI300X, NMEA port #3
NI300X, NMEA port #4
CI300X, Analog terminal
Not connected
Connection to Robnet
Junction unit: HS+, HS–
J50, Power PCB NMEA I/P RX2+,RX2–
NI300X, NMEA port #1
NI300X, NMEA port #2
NI300X, NMEA port #3
NI300X, NMEA port #4
CI300X, Analog terminal
Not connected
J50, Main PCB NMEA I/P RX1+,RX1–
J50, Power PCB NMEA I/P RX2+,RX2–
NI300X, NMEA port #1
NI300X, NMEA port #2
NI300X, NMEA port #3
NI300X, NMEA port #4
Not connected
J50, Main PCB NMEA I/P RX1+,RX1–
J50, Power PCB NMEA I/P RX2+,RX2–
NI300X, NMEA port #1
NI300X, NMEA port #2
NI300X, NMEA port #3
NI300X, NMEA port #4
Not connected
J50, Main PCB NMEA I/P RX1+,RX1–
J50, Power PCB NMEA I/P RX2+,RX2–
NI300X, NMEA port #1
NI300X, NMEA port #2
NI300X, NMEA port #3
NI300X, NMEA port #4
GI51 Pulse log terminal
J50 = All junction unit models
Connected to terminal
Assign hardware
port to set-up item
(* = default setting)
– – – –
ROBNET*
J50-HS
J50-2
NI300-1
NI300-2
NI300-3
NI300-4
CI300X
– – – – *
ROBNET
J50-HS
J50-2
NI300-1
NI300-2
NI300-3
NI300-4
CI300X
– – – – *
J50-1
J50-2
NI300-1
NI300-2
NI300-3
NI300-4
– – – – *
J50-1
J50-2
NI300-1
NI300-2
NI300-3
NI300-4
– – – – *
J50-1
J50-2
NI300-1
NI300-2
NI300-3
NI300-4
GI-LOG
20222469 / B
