Feature
Speed
Current
Table 3.3.: USB 2.0 Host Port Specification

3.2.3. RJ45 Ethernet Connectors

Specification
The two Ethernet ports are specified as follows:
Feature
Isolation
Speed
Mode
Crossover
Pin Assignment
Pin Signal
1 TX+
2 TX
3 RX+
4 -
5 -
6 RX
7 -
8 -
Table 3.5.: Pin Assignments of RJ45 Ethernet Connectors
NB1600 User Manual
Specification
Low, Full & Hi-Speed
max. 500mA
Specification
1500 Vrms
10/100 Mbps
Half- & Full-Duplex
Automatic MDI/MDI-X
Table 3.4.: Ethernet Port Specification
16
