Reattaching the image sensor unit
(1)
Reattach the image sensor unit by reversing the sequence of steps in which it was detached.
Align the image sensor with the front of the main unit when attaching the sensor.
CS1000-UM-251-03-9370
OK
Align
NG
Gap
8. DISASSEMBLING AND ADJUSTING MECHANICAL PARTS
Front
Align here.
8-32
