CS11 Hold-down unit EV maintenance (for CS1100)

No Parts No.
1
2
3
4
5
6
7
8
9 641110230 C1-J hold-down base
10 641110200 C1 hold-down CS
11 641000210 Hold-down side
12 641000820 Hold-down CS positioner
13 641000710 Hold-down EV caution label
14 641000441 Hold-down attachment
15 380101741 Pressure spring C-174
16 316422001 Ring latch C-42-2
CS1000-UM-251-03-9370
Description
AR-320
ARU-2015
M2 × 6 binding head screw (black)
M3 × 4 binding head screw (black)
M3 × 6 TP screw (black)
M3 × 6 binding head screw (black)
M3 × 6 flat head screw
M3 × 8 flat head screw
14-18
14. PARTS LISTS
Q'ty Remarks
1
3
3
4
1
4
8
1
1
1
2
1
1
2
3
2
