GRAPHTEC CS1000 Service Manual page 3

No. Date issued
1 01.11.12
8.10 Revised due to changed power supply unit in-
2 02.07.25
stallation positions
8.11 CIS Board (A/B) - Errors corrected
10.1 Adjustment details added due to addition of
CS1100 software adjustment
10.4 Shading (undesired line removal) - Revised
10.5 Resolution Adjustment Check - Revised
10.6 Color Difference Test Chart - Revised
14.1 Parts List - Jigs added
1 OVERVIEW
3 02.07.25
2.1 Part Names and Functions
3.6 Attaching the Document Support Wires
3.7 Document Hold-down Unit EV
8.9 Main Board
8.10 Power Boards
8.11 CIS (Charge Coupled Device Imaging Sensor)
Boards A and B
9.1 Wiring Diagrams
14.12 Accessory Changes from CS1000
14.13 Disassembled Views of Changed Parts
Adjustment details added due to addition of
CS1000EV/1100EV
4 04.02.16 Contents of the 2nd cautions corrected.
CS1000-UM-251-9370
HISTORY OF REVISIONS
Description of revision
First Printing
2
Page
All
8-12
8-13
10-1, 10-3,
10-5, 10-6, 10-8,
10-13 to 10-17
10-18 to 10-21
10-22
14-2
1-1 to 1-6
2-3
3-8, 3-9
3-10, 3-11
8-10 to 8-12
8-13, 8-14
8-15
9-1, 9-2, 9-4
14-16
14-17 to 14-19
8-3, 8-4
Edition
01
02
03
04
