2.2 Clear CMOS Setup

If want to clear the CMOS Setup (for example, forgetting
the password, the user should clear the setup and then set
the password again.), the user should close the JP1 about 3
seconds, then open again. For normal operation mode, just
open JP1.
• JP1: Clear CMOS Setup
JP1
1-2
2-3

2.3 BIOS Protection Setting

To protect the bios from writing, place the cap on the
location 2-3.
• JP2: Flash Protection Setting
JP2 DESCRIPTION
2-3 Locked
Unlocked
1-2

2.4 Keyboard Power Selection

• JP4: Keyboard Power Selection
JP4 DESCRIPTION
1-2 VCC
5VSB
2-3
DESCRIPTION
Keep CMOS Setup
(Normal Operation)
Clear CMOS Setup
12
