ICP Electronics ROCKY-3786EV User Manual page 49

Video Off In Suspend
This determines the manner in which the monitor is blanked.
The Choice: Yes, No.
Suspend Type
Select the Suspend Type.
The Choice: PWRON Suspend, Stop Grant.
Suspend Mode
When enabled and after the set time of system inactivity, all
devices except the CPU will be shut off.
The Choice: 1Min, 2Min, 4Min, 8Min, 12Min, 20Min, 30Min,
40Min, 1Hour, Disabled.
HDD Power Down
When enabled and after the set time of system inactivity, the
hard disk drive will be powered down while all other devices
remain active.
The Choice: 1Min, 2Min, 3Min, 4Min, 5Min, 6Min, 7Min, 8Min,
9Min, 10Min, 11Min, 12Min, 13Min, 14Min, 15Min, Disabled.
PM EVENTS
PM events are I/O events whose occurrence can prevent the
system from entering a power saving mode or can awaken the
system from such a mode. In effect, the system remains alert
for anything which occurs to a device which is configured as
Enabled , even when the system is in a power down mode.
Primary IDE 0
Primary IDE 1
Secondary IDE 0
Secondary IDE 1
FDD, COM, LPT Port
PCI PIRQ[A-D] #
49
