ROCKY-4782E2V
User Manual
Version 1.5
SOCKET 478 PENTIUM 4 with
Dual LAN & SiS 315 AGP4X VGA SBC
February 19, 2004
©Copyright 2004 by ICP Electronics Inc. All Rights Reserved

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the iEi ROCKY-4782E2V and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ICP Electronics iEi ROCKY-4782E2V

Summary of Contents for ICP Electronics iEi ROCKY-4782E2V

  • Page 1 ROCKY-4782E2V User Manual Version 1.5 SOCKET 478 PENTIUM 4 with Dual LAN & SiS 315 AGP4X VGA SBC February 19, 2004 ©Copyright 2004 by ICP Electronics Inc. All Rights Reserved...
  • Page 2 Trademarks ROCKY-4782E2V is a registered trademark of ICP Electronics Inc. IBM PC is a registered trademark of International Business Machines Corporation. Intel is a registered trademark of Intel Corporation. AWARD is a registered trademark of AWARD Software, Inc.

  • Page 3: Table Of Contents

    Table of Contents CHAPTER 1 INTRODUCTION ..............4 1.1 S .................. 4 PECIFICATIONS 1.2 P ................6 ACKAGE ONTENTS CHAPTER 2 INSTALLATION..............7 2.1 B .............. 8 OARD AYOUT AND IMENSIONS 2.2 U ............... 9 NPACKING RECAUTIONS 2.3 C CMOS S (JP2) ..............
  • Page 4 4.12 D ................42 EFAULT ENUS 4.13 S ............. 43 UPERVISOR ASSWORD 4.14 E ................. 44 XITING ELECTIONS APPENDIX A WATCHDOG TIMER............45 APPENDIX B I/O MAPPINGS..............47 APPENDIX C ATX POWER SUPPLY............49 APPENDIX D HOW TO USE THE WAKE-UP FUNCTION......51...

  • Page 5: Chapter 1 Introduction

    Chapter 1 Introduction Welcome to the ROCKY-4782E2V SOCKET 478 PENTIUM 4 Single Board Computer. The ROCKY-4782E2V board is an ISA/PCI form factor board, which comes with a high performance processor and advanced high performance multi-mode I/O, designed for the system manufacturers, integrators, or VARs that want to provide all the performance, reliability, and quality at a reasonable price.
  • Page 6 Chipset INTEL 845 (MCH) Real-time clock/calendar INTEL 82801(ICH2) RAM memory TWO 168-pin DIMM sockets supporting SDRAM. Supports up to 2GB of memory ATA/100 IDE Interface Up to four PCI Enhanced IDE hard disk drives are supported. The ATA/100 IDE can handle data transfer up to 100MB/s.

  • Page 7: Package Contents

    Keyboard and PS/2 mouse connector A 6-pin mini DIN connector is located on the mounting bracket for easy connection to a keyboard or PS/2 mouse. For alternative application, a keyboard and a PS/2 mouse connector are also available on board. Audio AC’97 Audio CODEC Compact Flash...

  • Page 8: Chapter 2 Installation

    Chapter 2 Installation This chapter describes how to install the ROCKY-4782E2V. These instructions include the layout and dimensions of the board and the unpacking precautions, which we recommend you to read carefully before you install the product. The instructions for jumper and switch settings for the ROCKY-4782E2V's configuration, such as CPU type selection, system clock setting, and Watchdog Timer, are also included.

  • Page 9: Board Layout And Dimensions

    Board Layout and Dimensions...

  • Page 10: Unpacking Precautions

    Unpacking Precautions Some components of ROCKY-4782E2V are very sensitive to static electric charges and can be damaged by a sudden rush of power. To protect it from unintended damage, be sure to note these precautions: Ground yourself to remove any static charge before touching the ROCKY-4782E2V SBC.

  • Page 11: Onboard Keyboard/Mouse Source Setting (Jp7)

    Onboard Keyboard/Mouse Source Setting (JP7) DESCRIPTION Vcc (+5V) 5VSB...

  • Page 12: Chapter 3 Connectors

    Chapter 3 Connectors This chapter describes how to connect peripherals, switches and indicators to the ROCKY-4782E2V board. A listing of the connectors on the board is shown in the following table. Table of Connectors CONNECTOR DESCRIPTION FAN1~FAN3 Fan Connectors ATX 20-PIN Power Connector ATX-12V CPU Power Source VGA 15-pin Female Connector IrDA connector...

  • Page 13: Floppy Drive Connector (Fdc1)

    Floppy Drive Connectors (FDC1) The ROCKY-4782E2V board is equipped with a 34-pin daisy-chain drive connector cable. FDC1: FDC Connector PIN DESCRIPTION PIN DESCRIPTION GROUND REDUCE WRITE GROUND GROUND GROUND INDEX# GROUND MOTOR ENABLE A# GROUND DRIVE SELECT B# GROUND DRIVE SELECT A# GROUND MOTOR ENABLE B# GROUND...

  • Page 14: Pci E-Ide Disk Drive Connector (Ide1, Ide2)

    PCI E-IDE Disk Drive Connector (IDE1, IDE2) You can attach four IDE (Integrated Device Electronics) hard disk drives on these two channels, which support Ultra-DMA100 IDE devices. We recommend the non-DMA100 devices be connected to the secondary IDE connector. IDE 1: Primary IDE Connector IDE 2: Secondary IDE Connector IDE1/IDE2 Interface Connector DESCRIPTION...

  • Page 15: Parallel Port (Cn4)

    Parallel Port (CN4) This port is usually connected to a printer. The ROCKY-4782E2V includes an on-board parallel port (CN4), accessed through a 26-pin flat-cable connector. CN4: Parallel Port Connector DESCRIPTION DESCRIPTION STROBE# DATA 0 DATA 1 DATA 2 DATA 3 DATA 4 DATA 5 DATA 6...

  • Page 16: Ouse Connector (Cn19, Cn23)

    CN5, CN8: Serial Port 10-pin Connector DESCRIPTION DATA CARRIER DETECT (DCD) RECEIVE DATA (RXD) TRANSMIT DATA (TXD) DATA TERMINAL READY (DTR) GROUND (GND) DATA SET READY (DSR) REQUEST TO SEND (RTS) CLEAR TO SEND (CTS) RING INDICATOR (RI) GROUND (GND) Keyboard &...

  • Page 17: External Switches And Indicators (Cn9, Cn10, Cn17)

    For alternative application, a keyboard connector is also available on board, located on CN19. CN19: 5-pin Header Keyboard Connector DESCRIPTION KEYBOARD CLOCK KEYBOARD DATA GROUND External Switches and Indicators (CN9, CN10, CN17) There are several external switches and indicators for monitoring and controlling your CPU board.

  • Page 18: Usb Port Connectors (Cn3, Cn11)

    USB Port Connectors (CN3, CN11) The ROCKY- 4782EV provide 4 built-in USB ports for the future expansion needs. CN3, CN11: USB Port Connectors DESCRIPTION DESCRIPTION GROUND DATA- DATA+ DATA+ DATA- GROUND IrDA Infrared Interface Port (CN7) The ROCKY-4782E2V’s built-in IrDA port supports the Serial Infrared (SIR) and the Amplitude Shift Keyed IR (ASKIR) interfaces.

  • Page 19: Fan Connectors (Fan1-Fan3)

    Fan Connectors (FAN1-FAN3) The ROCKY-4782E2V provides two CPU cooling fan connectors, which can supply 12V/500mA to the cooling fan. All connectors have the same pin assignments and there is a “rotation” pin in fan connector to transmit the fan’s rotation signal to system for the BIOS to detect the fan speed.

  • Page 20: Vga Connector (J3)

    3.11 VGA Connector (J3) The ROCKY-4782E2V has a built-in 15-pin VGA connector directly connects to your CRT monitor. J3: 15-pin Female Connector DESCRIPTION DESCRIPTION GREEN BLUE GROUND GROUND GROUND GROUND GROUND DDC DAT HSYNC VSYNC DDCCLK 3.12 Audio Connectors (CN12-CN14, CN20) The ROCKY-4782E2V has a built-in AC’97 AUDIO CODEC connected directly to your MIC-IN &...

  • Page 21: Atx 20-Pin & Atx-12V Power Connector

    3.13 ATX 20-Pin & ATX-12V Power Connector (J1, J2) This connector supports the ATX power functions such as Modem Ring-on, Wake-up on LAN and soft power off are supported by the ROCKY-4782E2V board. (Power sourced from the ROCKY-4782E2V board) J1: System DESCRIPTION DESCRIPTION 3.3V...

  • Page 22: Chapter 4 Award Bios Setup

    Chapter 4 AWARD BIOS Setup This chapter discusses the AWARD Setup program built into the BIOS. The Setup program allows the user to configure the system, which is then stored in battery-backed CMOS RAM so that the Setup information is retained after the power is turned off.
  • Page 23 FUNCTION Up Arrow Move to the previous item Down Arrow Move to the next item Left Arrow Move to the item on the left (menu bar) Right Arrow Move to the item on the right (menu bar) Main Menu: Quit without saving changes Submenus: Exit Current page to the next higher level menu Move Enter...

  • Page 24: Getting Help

    Getting Help Press F1 to pop up a small help window that describes the appropriate keys to use and the possible selections for the highlighted item. To exit the Help Window press <Esc> or the <F1> again. After making and saving system changes with Setup, if you discover that your computer no longer is able to boot, the Award BIOS supports an override to the CMOS settings which resets your system to its defaults.
  • Page 25 Standard CMOS Features Use this menu for basic system configuration. See Section 4.4 for details. Advanced BIOS Features Use this menu to set the Advanced Features available on your system. See Section 4.5 for details. Advanced Chipset Features Use this menu to change the values in the chipset registers and optimize your system's performance.

  • Page 26: Standard Cmos Setup

    Standard CMOS Setup The items in Standard CMOS Setup Menu are divided into 10 categories. Each category includes no, one or more than one setup items. Use the arrow keys to highlight the item and then use the <Page Up> or <Page Down> keys to select the value you want in each item.
  • Page 27 ITEM OPTIONS DESCRIPTION Date MM DD YYYY Set the system date. Time HH : MM : SS Set the system time Options are in its sub menu Press <Enter> to enter the sub Primary Master (described in Table 3) menu of detailed options Options are in its sub menu Press <Enter>...
  • Page 28 IDE Adapters The IDE adapters control the hard disk drive. Use a separate sub menu to configure each hard disk drive. CMOS Setup Utility – Copyright © 1984-2001 Award Software IDE Primary Master I DE HDD Auto-Detection Press Enter Item Help IDE Primary Master Auto 2557MB Menu Level...
  • Page 29 ITEM OPTIONS DESCRIPTION IDE HDD Press Enter Press Enter to auto-detect the HDD on this channel. Autodetection If detection is successful, it fills the remaining fields on this menu. None Selecting ‘manual’ lets you set the remaining fields on Primary Auto this screen.

  • Page 30: Advanced Bios Features

    Advanced BIOS Features CMOS Setup Utility – Copyright © 1984 – 2000 Award Software Advanced BIOS Features Virus Warning [Disabled] Item Help CPU L1 & L2 Cache [Enabled] _______________________ Quick Power On Self Test [Enabled] Menu Level First Boot device [Floppy] Second Boot device [HDD-0]...
  • Page 31 Quick Power On Self Test This category speeds up Power On Self Test (POST) after you power up the computer. If it is set to Enable, BIOS will shorten or skip some check items during POST. Options: Enabled, Disabled. First/Second/Third/Other Boot Device The BIOS will attempt to load the operating system from the devices in the specified sequence.
  • Page 32 Security Option Select whether the password is required every time the system boots or only when you enter setup. OPTION DESCRIPTION System The system will not boot and access to Setup will be denied if the correct password is not entered at the prompt.

  • Page 33: Advanced Chipset Features

    Advanced Chipset Features CMOS Setup Utility - Copyright ( C ) 1984-2001 Award Software Advanced Chipset Features DRAM Timing Selectable Item Help CAS Latency Time _______________________ Active to Precharge Delay Menu Level DRAM RAS# TO CAS# Delay DRAM RAS# Precharge Memory Frequency For Auto Dram Read Thermal Mgmt...
  • Page 34 System BIOS Cacheable Selecting Enabled allows caching of the system BIOS ROM at F0000h-FFFFFh, resulting in better system performance. However, if any program writes to this memory area, a system error may result. Options: Enabled, Disabled. Video BIOS Cacheable Select Enabled allows caching of the video BIOS, resulting in better system performance.

  • Page 35: Integrated Peripherals

    Integrated Peripherals CMOS Setup Utility – Copyright © 1984 – 2001 Award Software Integrated Peripherals On-Chip Primary PCI IDE [Enabled] Item Help IDE Primary Master PIO [ Auto] ____________________ IDE Primary Slave PIO [Auto] Menu Level IDE Primary Master UDMA [Auto] If your IDE hard drive supports IDE Primary Slave...
  • Page 36 Init Display First This item allows you to decide to activate the PCI Slot or AGP for a VGA card first. Options: PCI Slot,AGP IDE HDD Block Mode Block mode is also called block transfer, multiple commands, or multiple sector read/write.
  • Page 37 Parallel Port Mode Select an operating mode for the onboard parallel (printer) port. Select Normal, Compatible, or SPP unless you are certain your hardware and software both support one of the other available modes. Options: Normal, EPP, ECP, ECP/EPP ECP Mode Use DMA Select a DMA channel for the parallel port for use during ECP mode.

  • Page 38: Power Management Setup

    Power Management Setup The Power Management Setup allows you to configure you system to most effectively save energy while operating in a manner consistent with your own style of computer use. CMOS Setup Utility – Copyright © 1984 – 2001 Award Software Power Management Setup ACPI function [Disabled]...
  • Page 39 There are four selections for Power Management, three of which have fixed mode settings. OPTION DESCRIPTION Disabled (default) No power management. Disables all four modes Min. Power Saving Minimum power management. Doze Mode = 1 hr. Standby Mode = 1 hr., Suspend Mode = 1 hr., and HDD Power Down = 15 min.

  • Page 40: Pnp/Pci Configuration Setup

    Wake Up Events Wake Up events are I/O events whose occurrence can prevent the system from entering a power saving mode or can awaken the system from such a mode. In effect, the system remains alert for anything that occurs to a device configured as On, even when the system is in a power down mode.
  • Page 41 Reset Configuration Data Normally, you leave this field Disabled. Select Enabled to reset Extended System Configuration Data (ESCD) when you exit Setup if you have installed a new add-on and the system reconfiguration has caused such a serious conflict that the operating system cannot startup. Options: Enabled, Disabled.

  • Page 42: Pc Health Status

    4.10 PC Health Status This screen displays some statistics on your system’s state, like temperature, fan speed and voltage. CMOS Setup Utility – Copyright © 1984-2001 Award Software PC Health Status Item Help Current System1 Temp. 28℃ Current System2 Temp. 32℃...

  • Page 43: Default Menus

    Spread Spectrum This item allows you to enable/disable the spread spectrum modulate. Options: Enabled, Disabled. CPU Host/DRAM/PCI Clock This item allows you to select CPU/DRAM/PCI frequency. Options: Default, 133/33MHz, 136/34MHz…….. 4.12 Default Menus Selecting “Defaults” from the main menu shows you two options that are described below Load Fail-Safe Defaults When you press <Enter>...

  • Page 44: Supervisor/User Password

    4.13 Supervisor/User Password You can set either supervisor or user password, or both of then. The differences between are: Supervisor password: You can enter and change the options of the setup menus. User password: You can only enter the setup menus, but cannot change any settings except the user password When you select this function, the following message will appear at the center of the screen to assist you in creating a password.

  • Page 45: Exiting Selections

    4.14 Exiting Selections Save & Exit Setup Pressing <Enter> on this item asks for confirmation: Save to CMOS and EXIT (Y/N)? Y Pressing “Y” stores the selections made in the menus in CMOS – a special section of memory that stays on after you turn your system off. The next time you boot your computer, the BIOS configures your system according to the Setup selections stored in CMOS.

  • Page 46: Appendix A Watchdog Timer

    Appendix A Watchdog Timer The Watchdog Timer is a device to ensure that standalone systems can always recover from abnormal conditions that cause the system to crash. These conditions may have resulted from an external EMI or a software bug. When the system stops working, hardware on the board will perform a hardware reset (cold boot) to bring the system back to a known state.
  • Page 47 Sample assembly program: TIMER_PORT = 443H TIMER_START = 443H TIMER_STOP = 843H ;; Initialize Timer MOV DX, TIMER_PORT MOV AL, 8 ;;8 seconds OUT DX, AL MOV DX, TIMER_START IN AL, DX ;;Start counter W_LOOP: MOV DX, TIMER_STOP IN AL, DX MOV DX, TIMER_START IN AL, DX ;;Restart counter...

  • Page 48: Appendix B I/O Mappings

    Appendix B I/O Mappings I/O Address Mappings I/O ADDRESS DESCRIPTION 000-01F DMA Controller #1 020-021 Interrupt Controller # 1, Master 040-05F System Timer 060-06F Standard 101/102 keyboard Controller 070-07F Real time Clock, NMI Controller 080-0BF DMA Page Register 0A0-0BF Interrupt Controller # 2 0C0-0DF DMA Controller # 2 0F0-0F0...
  • Page 49 1st MB Memory Address Mappings MEMORY ADDRESS DESCRIPTION 00000-9FFFF SYSTEM MEMORY A0000-BFFFF VGA BUFFER C0000-CFFFF VGA BIOS E0000-FFFFF SYSTEM BIOS 100000 EXTENDED MEMORY IRQ Mappings DESCRIPTION DESCRIPTION IRQ0 System Timer IRQ8 RTC clock IRQ1 Keyboard IRQ9 IRQ FOR PCI STEERING IRQ2 IRQ Controller IRQ10 LAN IRQ3 COM2...

  • Page 50: Appendix Catx Power Supply

    Appendix C ATX Power Supply The following notes show how to connect ATX Power Supply to the backplanes and/or the ISBC card. The cables used here are shown below: For backplanes with ATX Connector Please disconnect the AC cord of the Power Supply from the AC source to prevent sudden electric surges to the board.
  • Page 51 For the backplanes with ATX power supply connector For some SBC without ATX power ON/OFF function, you can control the ATX power supply through backplane’s PS ON connector. Please refer to the figure below: For the backplanes with ATX connector, simply doing the following can make the connection: Connect the ON/OFF (ordinary one) switch to Pin 2 (PS ON) and Pin 3 (GND) of connector CN2...

  • Page 52: Appendix D How To Use The Wake-Up Function

    Appendix D How to Use the Wake-up Function The ROCKY-4782E2V provides two types of Wake Up functions. This page describes how to use the Modem Wake-Up and LAN Wake-Up. Wake-Up function is working while you use ATX power supply, Wake-Up By Modem Ring On: You must enable Wake Up On LAN/Ring in CMOS SETUP.
