- Page 1 ® JUKI- 745E Pentium with LCD/CRT & Ethernet ISA Bus SBC Ver 3.x User Manual Version 2.1 November 5, 2003 ©Copyright 2003 by ICP Electronics Inc. All Rights Reserved.
-
Page 2: Copyright Notice
Trademarks JUKI-745E is a registered trademarks of ICP Electronics Inc. IBM PC is a registered trademark of International Business Machines Corporation. Intel is a registered trademark of Intel Corporation. -
Page 3: Table Of Contents
Table of Contents CHAPTER 1. INTRODUCTION ..........2 ............3 PECIFICATIONS ............5 ACKAGE ONTENTS CHAPTER 2. INSTALLATION ..........6 JUKI-745E L .............6 AYOUT JUKI-745E ........8 ETTING THE ™ F .......... 10 LASH LCD V ..........10 OLTAGE ETTING CMOS S ........... 11 LEAR ETUP CMOS S... -
Page 4: Chapter 1. Introduction
Chapter 1. Introduction Thank you for choosing JUKI-745E Pentium® with HiQPro™ LCD/CRT and Ethernet Single Board Computer. The JUKI-745E board is an half-size ISA bus form factor board, which comes equipped with high performance Pentium® CPU and advanced high performance multi-mode I/O, designed for the system manufacturers, integrators, or VARs that want to provide all the performance, reliability, and quality at a reasonable price. -
Page 5: Specifications
1.1 Specifications The JUKI-745E Pentium® with C&T 69000 Chipset LCD/CRT & Ethernet Single Board Computer provides the following specification: ® CPU : Pentium MMX up to 233Mhz, AMD K6 processor up to • 300MHz, Cyrix 6x86MX and IDE C6 processor Chipset : ALI M1531/M1543 •... - Page 6 Ultra DMA/33 IDE Interface : Support up to four PCI • Enhance IDE hard drives. The Ultra DMA/33 IDE can handle data transfer up to 33MB/s. Best of all is that this new technology is compatible with existing ATA-2 IDE specifications so there is no need to change any of customer’s current accessory.
-
Page 7: Package Contents
1.2 Package Contents In addition to this User Manual, the JUKI-745E package includes the following items: JUKI-745E Pentium® with C&T 69000 Chipset LCD/CRT & Ethernet Single Board Computer RS-232/Printer Cable FDD/HDD Cable 6-pin Mini-Din to 5-pin Din Keyboard and Mouse Adapter Cable If any of these items is missing or damaged, please contact the dealer from whom you purchased the product. -
Page 8: Chapter 2. Installation
Chapter 2. Installation This chapter describes how to install the JUKI-745E. First, the layout of JUKI-745E is shown, then comes the unpacking precautions that you should be careful is described. After that comes jumpers and switches setting for JUKI-745E's configuration, such as CPU type selection, system clock setting, and watch dog timer, are all included. -
Page 10: Setting The Cpu Of Juki-745E
2.2 Setting the CPU of JUKI-745E JP1:BUS Clock & CPU CORE/BUS Freq ratio setting • CPU Clock Setting : CPU/SDRQAM CLK PCI BUS CLK 11-12 9-10 (MHZ) (MHZ) 66.8 33.4 37.5 27.5 68.5 34.25 83.3 33.3 83.3 41.65 • FREQ RATIO : RATIO 1.5 x 2.0x... - Page 11 • Power module JP1 CPU Core Voltage Select 9-10 Voltage 3.5V 3.4V 3.2V 2.9V 2.8V 2.2V 2.0V • JP34 & JP35 : CPU Single / Dual Power type setting JP34 JP35 1-2 OFF SINGLE 3-4 OFF 1-2 OFF 1-2 ON DUAL 3-4 OFF 3-4 ON...
-
Page 12: Diskonchip™ Flash Disk
• AMD K6 MMX Rating Table, dual voltage Product Name Core Freq Vcore Bus MHz Multiplier K6-233 model 6 233MHz 3.2V 3.5x K6-200 model 6 200MHz 2.9V K6-166 model 6 166MHz 2.9V 2.5x K6-300 model 7 300MHz 2.2V 4.5x K6-266 model 7 266MHz 2.2V K6-233 model 7... -
Page 13: Clear Cmos Setup
2.5 Clear CMOS Setup If you want to clear CMOS Setup (for example you have forgotten the password then you should clear setup, then reset the password), you should close the CN34 pin 2-3 about 3 seconds, then open it again. To set back to normal operation mode, close pin 2-3. -
Page 14: Chapter 3. Connection
Chapter 3. Connection This chapter describes how to connect peripherals, switches and indicators to the JUKI-745E board. 3.1 Floppy Disk Drive Connector JUKI-745E board is equipped with a 34-pin daisy-chain driver connector cable. • CN25 : FDC CONNECTOR PIN NO. DESCRIPTION PIN NO. -
Page 15: Pci E-Ide Disk Drive Connector
3.2 PCI E-IDE Disk Drive Connector You can attach up to four IDE( Integrated Device Electronics) hard disk drives to the JUKI-745E IDE controller. The IDE support Ultra DMA/33 interface. • CN21: IDE Interface Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION RESET# GROUND... -
Page 16: Parallel Port
3.3 Parallel Port This port is usually connected to a printer. JUKI-745E includes an on-board parallel port, accessed through a 26-pin flat-cable connector CN26. • CN26 : Parallel Port Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION STROBE# AUTO FORM FEED # DATA 0 ERROR # DATA 1... -
Page 17: Serial Ports
3.4 Serial Ports The JUKI-745E offers two high speed NS16C550 compatible UARTs with Read/Receive 16 byte FIFO serial ports. • CN27 : Serial Port DB-9 Connector( COM1 ) PIN NO. DESCRIPTION DATA CARRIER DETECT (DCD) RECEIVE DATA (RXD) TRANSMIT DATA (TXD) DATA TERMINAL READY (DTR) -
Page 18: Keyboard / Mouse Connector
3.5 Keyboard / Mouse Connector The JUKI-745E provides two keyboard/Mouse connectors. • CN37 : 5-pin Header Keyboard Connector PIN NO. DESCRIPTION KEYBOARD CLOCK KEYBOARD DATA GROUND • CN35 : 5-pin Header Mouse Connector PIN NO. DESCRIPTION MOUSE DATA GROUND MOUSE CLOCK •... -
Page 19: External Switches And Indicators
3.6 External Switches and Indicators There are many external switches and indicators for monitoring and controlling your CPU board. • CN2: Speaker Connector PIN NO. DESCRIPTION Speaker Signal • CN38 : Reset Connector PIN NO. DESCRIPTION External Reset GROUND • CN32 : IDE LED Connector PIN NO. -
Page 20: External Battery Connector
3.7 External Battery Connector The JUKI-745E has built-in a 3V/850mAH industrial Li-battery for CMOS and RTC backup. During normal operation, it will not need external battery to backup the data. If you want to connect an external battery to the board, you could take off the CN34’s pin 2- 3 jumper, then connect the external battery to pin 1-4. -
Page 21: Lan Rj45 Connector
PLCD PLCD SHFCLK ENABKL` FPVDD FPVEE +12V +12V 3.9 Lan RJ45 Connector The JUKI-745E built-in a RJ45 Lan connector. • CN30 : Lan RJ45 Connector • CN39 LED Connector(2-pin header) for Lan LED2: 10M LED1: 100M LED0: TX/RX (Note: 1,3,5: VCC) -
Page 22: Usb Port
3.10 USB Port The JUKI-745E has one built-in USB port for the future new I/O bus expansion. • JP41:USB Port PIN NO. DESCRIPTION USBP0- USBP0+ GROUND 3.11 IO Address Map IO Address Map I/O Address DESCRIPTION Range 000-01F DMA Controller # 1 020-021 Interrupt Controller # 1, Master 040-05F... - Page 23 380-38F SDLC, Bisynchronous 2 3A0-3AF Bisynchronous 1 3B0-3BF Monochrome Display and Printer Adapter (LPT1) 3C0-3CF Reserved 3D0-3DF Color/Graphics Monitor Adapter 3E8-3EF Serial Port 3 Diskette Controller,ALI1543 CONFIG INDEX 3F0-3F7 PORT(3F0) 3F8-3FF Serial Port 1 Watch dog timer enable Watch dog timer disable 1 st MB Memory Address Map Memory address Description 00000-9FFFF...
- Page 24 DMA Channel Assignments Channel Function Available Available Flopp disk (8-bit transfer) Available Cascade for DMA controller 1 Available Available Available...
-
Page 25: Chapter 4. Ami Bios Setup
Chapter 4. AMI BIOS Setup The JUKI-745E uses the AMI BIOS for system configuration. The AMI BIOS setup program is designed to provide maximum flexibility in configuring the system by offering various options which may be selected to meet end-user’s needs. This chapter is written to assist you in the proper usage of these features. -
Page 26: Standard Cmos Setup
4.2 Standard CMOS Setup The Standard CMOS Setup is used for basic hardware system configuration. The main function is for Date/Time setting and Floppy/Hard Disk Drive setting. For IDE hard disk drive setup, please check the following possible setup procedure: Use Auto setting for detection during boot up.
