Appendix B. Address Mapping

IO Address Map

I/O address
Range
000-01F
020-021
040-05F
060-06F
070-07F
080-09F
0A0-0BF
0C0-0DF
0F0
0F1
0F2
0F8-0FF
1F0-1F8
200-207
278-27F
2E8-2EF
2F8-2FF
300-31F
360-36F
378-37F
3B0-3BF
3C0-3CF
3D0-3DF
3E8-3EF
3F0-3F7
3F8-3FF
Description
DMA Controller #1
Interrupt Controller #1, Master
8254 Timer
8042 (Keyboard Controller)
Real Time Clock, NMI Mask
DMA Page Register
Interrupt Controller #2
DMA Controller #2
Clear Math Coprocessor Busy
Reset Math Coprocessor
Core Logic Programming Configuration
Math Coprocessor
Fixed Disk
Game I/O
Parallel Printer Port 2 (LPT3)
Serial Port 4
Serial Port 2
Prototype Card
Reserved
Parallel Printer Port 1 (LPT2)
Monochrome Display and Printer Adapter
(LPT1)
Reserved
Color/Graphics Monitor Adapter
Serial Port 3
Diskette Controller
Serial Port 1
59
