Keyboard Connector - ICP Electronics ROCKY-3786EV User Manual

• CN8: COM2 10-pin Connector
PIN NO. DESCRIPTION
1 DATA CARRIER DETECT
2 RECEIVE DATA
3 TRANSMIT DATA
4 DATA TERMINAL READY (DTR)
5 GROUND
6 DATA SET READY
7 REQUEST TO SEND
8 CLEAR TO SEND
9 RING INDICATOR
10 NC

3.5 Keyboard Connector

The ROCKY-3786EVG provides 5-PIN Header and 6-PIN
keyboard/mouse connector.
• CN23: 6-pin Mini-DIN Keyboard/Mouse Connector
PIN NO.
1
2
3
4
5
6
• CN22: 5-pin Keyboard Connector
PIN NO.
1
2
3
4
5
(DCD)
(RXD)
(TXD)
(DSR)
(RTS)
(CTS)
(RI)
DESCRIPTION
KEYBOARD DATA
MOUSE DATA
GROUND
+5V
KEYBOARD CLOCK
MOUSE CLOCK
DESCRIPTION
KEYBOARD CLK
KEYBOARD DATA
N/C
GROUND
+5V
1 6
5 10
