ICP Electronics WAFER-5825 Manual

Low power gx1-300 mmx with svga/lcd, cardbus ethernet, & audio sbc
Hide thumbs
Table of Contents

Advertisement

Quick Links

Enlarged version
WAFER-5825
Low Power GX1-300 MMX
with SVGA/LCD, CardBus
Ethernet, & Audio SBC.
Copyright Notice
©Copyright 2001 by ICP Electronics Inc. All Rights Reserved. Manual first edition May 1,
2001.
The information in this document is subject to change without prior notice in order to
improve reliability, design and function and does not represent a commitment on the part
of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, electronic, or
other means in any form without prior written permission of the manufacturer.
Trademarks
WAFER-5825 is a registered trademark of ICP Electronics Inc. IBM PC is a registered
trademark of International Business Machines Corporation. Intel is a registered
trademark of Intel Corporation. Other product names mentioned herein are used for
identification purposes only and may be trademarks and/or registered trademarks of their
respective companies
Ver 1.2
1
Contents
Introduction ............................................................................4
1.1 Specifications.....................................................................4
1.2 What You Have..................................................................6
Installation ..............................................................................7
2.2 Unpacking Precautions ......................................................9
2.3 System Memory DRAM .....................................................9
2.4 Watch-Dog Timer Setting...................................................9
2.5 Clear CMOS Setup ..........................................................10
2.6 LCD Vcc Voltage Selector................................................10
Connection ........................................................................... 11
3.1PCI E-IDE Disk Drive Connector (CN2) ............................11
3.2 Parallel Port (CN11).........................................................13
3.3Serial Ports (CN14, CN12)................................................13
3.4 Audio Connector ..............................................................14
3.6 USB Port Connector (CN17)............................................15
3.7 IrDA Infrared Interface Port (CN5)....................................16
3.8 VGA Connector (CN13) ...................................................16
3.9 LCD Interface Connector .................................................16
3.10 LAN RJ45 Connector.....................................................18
3.11 External Power Connector .............................................18
3.12 Power and HDD LEDS...................................................19
3.13 Reset Button..................................................................19
3.14 Debug Port ....................................................................19
3.15 CardBus Connector .......................................................19
3.16 Buzzer Connector ..........................................................20
2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WAFER-5825 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ICP Electronics WAFER-5825

Summary of Contents for ICP Electronics WAFER-5825

  • Page 1: Table Of Contents

    3.8 VGA Connector (CN13) ...........16 Trademarks 3.9 LCD Interface Connector ..........16 WAFER-5825 is a registered trademark of ICP Electronics Inc. IBM PC is a registered 3.10 LAN RJ45 Connector.............18 trademark of International Business Machines Corporation. Intel is a registered 3.11 External Power Connector ..........18 trademark of Intel Corporation.

  • Page 2: Introduction

    3½" hard drive. It supports the full functions of an 4.4 CHIPSET FEATURES SETUP........25 AT-compatible industrial computer on a single board. The WAFER-5825 is equipped with a low-power consumption and high 4.5 POWER MANAGEMENT SETUP ........26 performance GX1-300 processor on board. It also contains an 4.6 PNP / PCI CONFIGURATION .........

  • Page 3: What You Have

    Supports 18-bit TFT LCD panel resolution up to 1024x768 @ following materials are included in the package: 18bpp • 1 Wafer-5825 All-in-one single board computer Supports non-interlaced CRT monitor’s resolutions up to • 1 CD disk for utility and drivers...

  • Page 4: Installation

    Installation This chapter gives instructions about how to set up the WAFER-5825 hardware, including directions of setting jumpers and connecting peripherals, switches and indicators. Before installation, please pay attention to the unpacking precautions on the following page for safety. 2.1 Wafer-5825 Block Diagram & Board Layout...

  • Page 5: Unpacking Precautions

    3 seconds, then open it again. Opening JP3 can set the CMOS back to normal operation mode, Ground yourself to remove any static charge before touching the Wafer-5825 SBC. You can do it by using a grounded wrist JP3 Clear CMOS Setup (Reserved Function) •...

  • Page 6: Connection

    CN1: Secondly IDE Interface Connector • 3.1 PCI E-IDE Disk Drive Connector (CN2) DESCRIPTION DESCRIPTION For IDE HDD connection, The Wafer-5825 was designed with one 2.0mm connector (CN2), which could be converted to two RESET# GROUND 2.54mm standard IDE connector via proprietary cable. Using...

  • Page 7: Parallel Port (Cn11)

    DATA CARRIER DETECT (DCD) 3.2 Parallel Port (CN11) RECEIVE DATA (RXD) TRANSMIT DATA (TXD) This port is usually connected to a printer. The WAFER-5825 DATA TERMINAL READY (DTR) includes an on-board parallel port (CN11), accessed through a GROUND (GND) 26-pin flat-cable connector.

  • Page 8: Keyboard & Ps/2 Mouse Connector (Cn16)

    Pin 5-6 can be used as input port if it is connected to the earphone jack of your CD. Pin 7-8 is for microphone. 3.7 IrDA Infrared Interface Port (CN5) The WAFER-5825’s built-in an IrDA port which supports Serial PIN NO. DESCRIPTION PIN NO.

  • Page 9: Lan Rj45 Connector

    CN3: LCD Interface Connector – only supports up to 18 bit LCD. • For better display quality, the length of LCD cable should The WAFER-5825’s built-in RJ45 LAN connector is for be shorter than 35 cm. 10/100Mbps Ethernet (RTL8139C). CN15: LAN RJ45 Connector •...

  • Page 10: Power And Hdd Leds

    IORD# PIN NO. Description PIN NO. Description IOWR# VS2# RESET WAIT# INPACK# REG# BVD2 BVD1 RSTDRV IOW# CD2# 3.15 CardBus Connector 3.16 Buzzer Connector The WAFER-5825 built-in a CardBus interface connector (CN4) • SP1: Buzzer Connector CN4: CardBus Connector •...

  • Page 11: Award Bios Setup

    AWARD BIOS Setup Floppy/Hard Disk Drive setting. Please refer the following screen for this setup. WAFER-5825 uses the AWARD PCI/ISA BIOS for system configuration. The AWARD BIOS setup program is designed to provide maximum flexibility in configuring the system by offering various options that may be selected to meet end-user requirements.

  • Page 12: Bios Features Setup

    2. Use the IDE HDD AUTO DETECTION in the main menu, 4.3 BIOS FEATURES SETUP computer will automatically detect This BIOS Features Setup is designed for the 'fine tuning' of specifications. your system in order to improve its performance. As for normal 3.

  • Page 13: Chipset Features Setup

    Please, Power Management Setup helps user to handle the carefully change any default setting, otherwise the system will WAFER-5825 board‘s “green” function. This feature can shut run unstable. down the video display and hard disk to save energy, for example.

  • Page 14: Pnp / Pci Configuration

    4.6 PNP / PCI CONFIGURATION 4.7 LOAD BIOS DEFAULTS This menu is used to assign certain IRQ to your PNP/PCI devices manually. PNP OS Installed: if you install Plug and Play operating If you select 'Y' to this field, the BIOS Defaults will be loaded system (OS), the OS will reassign the interrupt if you select except Standard CMOS SETUP.

  • Page 15: Load Setup Defaults

    4.9 INTEGRATED PERIPHERALS 4.8 LOAD SETUP DEFAULTS This option is used to assign Onboard I/O, IRQ, DMA etc. If you don't know how to configure them, just press <F7> to load If you select 'Y' to this field, the Setup Defaults will be loaded Setup Defaults.

  • Page 16: Supervisor Password And User Password

    Audio Low DMA Select -- DMA0, DMA1, DMA3, Disabled 4.10 SUPERVISOR PASSWORD AND USER PASSWORD To select the high DMA channel. Supervisor Password sets a password that is used to protect Audio High DMA Select -- DMA5, DMA6, DMA7, Disabled your system and Setup Utility.

  • Page 17: Ide Hdd Autodetection

    4.12 SAVE & EXIT SETUP 4.11 IDE HDD AUTODETECTION Select this option when you finish setting all the parameters and This option detects the parameters of an IDE hard disk drive want to save them into the CMOS. Just simply press <Enter> key (HDD sector, cylinder, head, etc) automatically and will put the and all the configuration changes will be saved parameters into the Standard CMOS Setup screen.

  • Page 18: Exit Without Saving

    The WAFER-5825 is equipped with on-board LCD/VGA interface. The description below is its specifications and features: 5.1.1 Chipset The WAFER-5825 uses a Cyrix CX5530 chipset as its SVGA controller. It is compatible with many common 18-bit LCD displays and traditional analog CRT monitors. The VGA BIOS supports LCD.

  • Page 19: Further Information

    Vga \ MediaGX \ Win9X \ National Geode Win9x Drivers1.2.exe 6.1 Introduction With on-board audio interface, the WAFER-5825 can perform 2. WinNT4.0 drivers in driver CDROM high-quality stereo sound and FM music synthesis (ESFM) by Vga \ MediaGX \ Nt40 \ using the CX5530 audio controller.

  • Page 20: Pci Bus Ethernet Interface

    7.1 Introduction 8.1 Introduction The WAFER-5825 provides a high performance 32-bit Ethernet The WAFER-5825 provides a high performance 32-bit PCI bus chipset which is completely compliant with IEEE 802.3 100 Mbps Interface to CardBus interface chipset, which can support the CSMA/CD standards.

  • Page 21: Support

    Appendix A. Watch-Dog Timer 8.2 Support The WatchDog Timer is a device to ensure that standalone In the CardBus standard adopted by PC Card 95, the data systems can always recover from catastrophic conditions that transfer bus was extended to 32bit and bus clock became 33MHz. cause the CPU to crash.
  • Page 22 ;; ADD YOUR APPLICATION HERE 543H. This must be done within the time out period that is selected by software, please refer to the example program. W_LOOP: MOV DX, TIMER_STOP A tolerance of at least 5% must be maintained to avoid unknown routines within the operating system (DOS), such as disk I/O that IN AL, DX can be very time consuming.

  • Page 23: Appendix B. I/O Address Map

    Appendix B. I/O Address Map Audio High DMA select: DMA 1.3 B.1 System I/O Address Map Audio Low DMA select: DMA 5.6.7 I/O Address Map Description ** Parallel port DMA default setting: DMA 3 000-01F DMA Controller #1 020-021 Interrupt Controller # 1, Master Parallel port DMA select: DMA 1.3 022-023 Chipset address...
  • Page 24 B.4 1 MB memory map Address Description F000h-FFFFh System ROM D800h-EFFFh Unused C800h-D7FFh Ethernet ROM* C000h-C7FFh Expansion ROM* B800h-BFFFh CGA/EGA/VGA text B000h-B7FFh Unused A000h-AFFFh EGA/VGA graphics 0000h-9FFFh Base memory D000-D400H Available * Default setting ** If Ethernet boot ROM is enabled.
