be required to preserve the integrity of the data held in the
slower memory chips.
SDRAM CAS Latency Time
When synchronous DRAM is installed, the number of clock
cycles of CAS latency depends on the DRAM timing.
The Choice: 2, 3
SDRAM Cycle Time Tras/Trc
Select the number of SCLKs for an access cycle.
The Choice: 5/7, 6/8.
SDRAM RAS-to-CAS Delay
This field lets the user insert a timing delay between the CAS
and RAS strobe signals, used when DRAM is written to, read
from, or refreshed. Fast gives faster performance; and Slow
gives more stable performance. This field applies only when
synchronous DRAM is installed in the system.
The Choice: 2, 3.
SDRAM RAS Precharge Time
If an insufficient number of cycles is allowed for the RAS to
accumulate its charge before DRAM refresh, the refresh may be
incomplete and the DRAM may fail to retain data. Fast gives
faster performance; and Slow gives more stable performance.
This field applies only when synchronous DRAM is installed in
the system.
The Choice: 2, 3.
System BIOS Cacheable
Selecting Enabled allows caching of the system BIOS ROM at
F0000h-FFFFFh, resulting in better system performance.
However, if any program writes to this memory area, a system
error may result.
The Choice: Enabled, Disabled.
