4.11 PC Health Status

CMOS Setup Utility – Copyright © 1984-2000 Award Software
CPU VCORE
VTT
+3.3V
+5V
+12V
-12V
-5V
+5VSB
Voltage Battery
CPU Temperature
System Temperature
Fan 2 Spend
Fan 3 Spend
↑↓←→ Move Enter: Select +/-/PU/PD: Value F10:Save ESC: Exit
F1:General Help
F5:Previous Values
Note: Normally, the CPU Fan RPM is over than 5000 RPM. If the
user's CPU Fan RPM is less than this figure, something is
wrong and the CPU will be in overheat condition. Make
sure that the connection at Fan1/Fan2 is correct.
