4. Award BIOS Setup

4.1 Introduction

This chapter discusses the Setup program written in the BIOS.
It will give the user a step-by-step guidance to configure the
system. The user-defined configuration is then stored in
battery-backed CMOS RAM, which retains the customized
information when power is turned off.

4.2 Starting Setup

The BIOS is immediately active when the user turn on the
computer. While the BIOS is in control, the Setup program can
be activated in one of two ways:
1. By pressing <Del> immediately after switching the system
on, or
2. By pressing the <Del> key when the following message
appears at the bottom of the screen during POST (Power On
Self-Test):
Press DEL to enter SETUP
If the message passed before the user can respond to it and the
user still wish to enter Setup, please turn off the power to
restart the system; or simply press the "RESET" button on the
system case to reboot.
simultaneously pressing <Ctrl>, <Alt>, and <Delete> keys. If
the user do not press the keys at the right timing and the
system does not boot, an error message will be displayed and
the user will prompted to...
PRESS F1 TO CONTINUE, DEL TO ENTER SETUP
The user may also restart by
26
