• CN16: Left/Right Audio LINE-OUT Phone-Jack
Connector, same output as LINE-OUT in
CN14
1. GROUND
2. LEFT SIGNAL
3. NC
4. RIGHT SIGNAL
5. NC
3.12 Compact Flash Storage Card Socket
(Optional)
The ROCKY-3786EV/EVG(U2) configures Compact Flash
Storage Card in IDE Mode. This type II Socket is
compatible with IBM Micro Drive.
• CN25: Compact Flash Storage Card Socket pin
assignment
PIN NO. DESCRIPTION
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
PIN NO.
GROUND 26
D3 27
D4 28
D5 29
D6 30
D7 31
CS1# 32
N/C 33
GROUND 34
N/C 35
N/C 36
N/C 37
VCC 38
N/C 39
N/C 40
DESCRIPTION
CARD DETECT1
D11
D12
D13
D14
D15
CS3#
N/C
IOR#
IOW#
OBLIGATORY TO
PULL HIGH
IRQ15
VCC
MASTER/SLAVE
N/C
23
