ICP Electronics ROCKY-3786EV User Manual page 8

Watchdog timer
VGA Controller
Intel 82801BA
embedded LAN
and Inter 82540
Giga Controller
Keyboard
Controller
Power
Consumption
Operating
Temperature
From 1 second to 255 second
Reset will be generated when CPU did not
periodically trigger the timer
Embedded VGA controller, Screen Resolution: up
to 1600x1200 in 256 Colors at 85Hz refresh.
IEEE 802.3u Auto-Negotiation support for
10BASE-T/100BASE-TX
standard
Fast back-to-back transmission support with
minimum interframe spacing
Connected to the user's LAN through RJ45
connector
8042 compatible for keyboard and PS/2 mouse
5V/9A and 12V/0.1A, as running by PIII 933MHz
and 256MB
0 ° ~ 55 ° C (CPU needs Cooler)
and 1000BASE-TX
8
