ROCKY-3732EVS
Dual Pentium® III with
Dual 10/100Mb Ethernet , VGA, Audio,
Dual Ultra-160 SCSI Port
Ver 2.x
@Copyright 2001
All Rights Reserved.
Manual first edition Jan 14, 2001
The information in this document is subject to change without prior
notice in order to improve reliability, design and function and does
not represent a commitment on the part of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special,
incidental, or consequential damages arising out of the use or
inability to use the product or documentation, even if advised of the
possibility of such damages.
This document contains proprietary information protected by
copyright. All rights are reserved. No part of this manual may be
reproduced by any mechanical, electronic, or other means in any
form without prior written permission of the manufacturer.
Trademarks
ROCKY-3732EVS is registered trademarks of ICP Electronics Inc.,
IBM PC is a registered trademark of International Business Machines
Corporation. Intel is a registered trademark of Intel Corporation.
AWARD
is
registered
trademarks
of
AWARD
SOFTWARE
INTERNATIONAL, Inc. Other product names mentioned herein are
used for identification purposes only and may be trademarks and/or
registered trademarks of their respective companies.
1
Advertisement
Table of Contents
Related Manuals for ICP Electronics ROCKY-3732EVS
Summary of Contents for ICP Electronics ROCKY-3732EVS
- Page 1 Trademarks ROCKY-3732EVS is registered trademarks of ICP Electronics Inc., IBM PC is a registered trademark of International Business Machines Corporation. Intel is a registered trademark of Intel Corporation.
-
Page 2: Table Of Contents
1. Introduction ............5 Specifications.................. 6 What You Have................7 2. Installation ............8 ROCKY-3732EVS's Layout............. 9 Clear CMOS Setup ............... 10 CompactFlash Card Master/Slave Mode Setting ......10 CPU Type Selection Setting ............10 SCSI A/B Terminator Selection Setting ........11 3. - Page 3 3.10 VGA Connector................18 3.11 Audio Connectors ................ 19 3.12 CompactFlash Storage Card Socket ........... 20 3.13 ATX Connector ................21 3.14 External Switches and Indicators ..........22 3.15 PS-ON Connector ................ 22 3.16 LAN RJ45 Connectors ..............23 3.17 External LED Connector .............. 23 3.18 Ultra-2/3 68pin SCSI Connectors ..........
- Page 4 4.15 Exit Selecting ................55 Appendix A. WatchDog Timer......56 Appendix B. E Key™ Function......57 Appendix C. Address Mapping......59 Appendix D. ATX Power Supply ......61 Appendix E. How to used Wake Up Function ..63 Appendix F. Dimensions ........64...
-
Page 5: Introduction
Introduction The ROCKY-3732EVS ATX/AT mainboard is a high- performance computer mainboard based on VIA ® VT82C694X/T chipset. The ROCKY-3732EVS is designed for Intel Pentium III (FC-PGA) processor for cost-effective ® ® server markets. The Apollo Pro133A (VT82C694X/T) is a Socket-370 system logic north bridge with the addition of 133 MHz capability for both the CPU and SDRAM interfaces. -
Page 6: Specifications
1.1 Specifications : • CPU : Dual Pentium® III (FC-PGA / FC-PGA2 (694T only)) &, Celeron™ (PPGA ) • FBS : Support 66/100/133 MHz(Auto Detect) • : PICMG Bus(Support PCI Master x 4) • DMA channels : 7 • Interrupt levels : 15 •... -
Page 7: What You Have
• Mouse : PS/2 Mouse Port on-board. • Operating Temperature : 0° ~ 55° C ( CPU needs Cooler) What You Have In addition to this User's Manual, the ROCKY-3732EVS package includes the following items: • ROCKY-3732EVS Celeron Pentium Single Board ®,... -
Page 8: Installation
Installation This chapter describes how to install the ROCKY-3732EVS. At first, the layout of ROCKY-3732EVS is shown, and the unpacking information that you should be careful is described. The jumpers and switches setting for the ROCKY-3732EVS's configuration, such as CPU type selection, system clock... -
Page 9: Rocky-3732Evs's Layout
ROCKY-3732EVS's Layout CN21 CN19 CN20... -
Page 10: Clear Cmos Setup
2.2 Clear CMOS Setup If want to clear the CMOS Setup(for example forgot the password you should clear the setup and then set the password again.),you should close the JP3(2-3) about 3 seconds, then open again. Set back to normal operation mode. •... -
Page 11: Scsi A/B Terminator Selection Setting
2.5 SCSI Port A/B Terminator Selection Setting Two SCSI terminators Port A and Port B are supported, JP5 is for Terminator Port A and JP6 is for Terminator Port B • JP5, JP6 : Terminator Enable/Disable Setting ¦ ¦ ¨ JP5, JP6 DESCRIPTION Enable... -
Page 12: Connection
This chapter describes how to connect peripherals, switches and indicators to the ROCKY-3732EVS board. 3.1 Floppy Disk Drive Connector ROCKY-3732EVS board is equipped with a 34-pin daisy-chain driver connector cable. • CN2 : FDC CONNECTOR 6 … 30 32 34 ¡... -
Page 13: Pci E-Ide Disk Drive Connector
3.2 PCI E-IDE Disk Drive Connector You can attach four IDE( Integrated Device Electronics) device to the VT82C686B IDE controller. IDE2 shares the same IDE channel with CompactFlash, so you must refer JP4 before setting the IDE2’s device. CN5 (IDE1) : Primary IDE Connector CN6 (IDE2) : Secondary IDE Connector •... -
Page 14: Parallel Port
3.3 Parallel Port This port is usually connected to a printer, The ROCKY-3732EVS includes an on-board parallel port, accessed through a 26-pin flat- cable connector CN11. • CN11 : Parallel Port Connector 6 … 22 24 26 ¡ ¡ ¡ … ¡ ¡ ¡... -
Page 15: Usb Port Connector
3.4 USB Port Connector The ROCKY-3732EVS built in two USB(Spec. 1.1) ports for the future new I/O bus expansion. CN3 : 2 ports USB Connector Pin 1-4 for USB 1 Pin 5-8 for USB 0 ¡ ¡ ¡ ¡ ¨ ¡ ¡ ¡... -
Page 16: Serial Ports
3.6 Serial Ports The ROCKY-3732EVS offers two high speed NS16C550 compatible UARTs with 16 byte Read/Receive FIFO serial ports. CN9 : COM1 CN10 : COM2 • CN9/CN10 : Serial Port 10-pin Connector 7 8 9 10 ¡ ¡ ¡ ¡ ¡... -
Page 17: Irda Infrared Interface Port
KEYBOARD DATA GROUND 3.8 IrDA Infrared Interface Port The ROCKY-3732EVS built in a IrDA port which supports Serial Infrared(SIR) or Amplitude Shift Keyed IR(ASKIR) interface. When you use the IrDA port, you have to set COM2 as SIR or ASKIR mode in the BIOS’s Peripheral Setup. Then the RS-232 mode of COM2 will be disabled. -
Page 18: Fan Connector
3.9 Fan Connector The ROCKY-3732EVS provides CPU with cooling fan connector and chassis fan connector. These connectors can supply 12V/500mA to the cooling fan. There is a “rotation” pin in fan connector. This rotation pin is to get the fan’s rotation signal to system. -
Page 19: Audio Connectors
3.11 Audio Connectors The onboard AC’97 Codec supports several audio functions. The audio connectors are described as below. CN19/CN20/CN21/CN22 Connector ¦ ¦ ¦ ¨ CN19 : LINE IN PIN NO. DESCRIPTION LEFT SIGNAL GROUND GROUND RIGHT SIGNAL CN21 : CD IN PIN NO. -
Page 20: Compactflash Storage Card Socket
3.12 CompactFlash Storage Card Socket The ROCKY-3732EVS configures CompactFlash Storage Card in IDE Mode(Used IDE 2). • CN4 : CompactFlash Storage Card Socket pin assignment PIN NO. DESCRIPTION PIN NO. DESCRIPTION GROUND CARD DETECT1 CS1# CS3# GROUND IOR# IOW# OBLIGATORY... -
Page 21: Atx Connector
3.13 ATX Connector The ROCKY-3732EVS offers one standard ATX power connector • CN12: 20-pin Connector 10 20 ¡ ¡ ¡ ¡ ¡ ¡ ¨ ¡ 1 11 PIN NO. DESCRIPTION Power Good +5V SB +12V -12V PSON#... -
Page 22: External Switches And Indicators
3.14 External Switches and Indicators There are several external switches and indicators for monitoring and controlling your CPU board. All the functions are in the CN23 connector. CN23 Pin Assignment and Functions : 6 8 10 12 ¡ ¡ ¡ ¡ ¡ ¡ ¨... -
Page 23: Lan Rj45 Connectors
3.16 LAN RJ45 Connector ROCKY-3732EVS equipped with dual Intel 82559 10/100Mbps Ethernet Controllers. You can connect it to your LAN through RJ45 LAN connector. The pin assignments are as follows: • CN16/CN18 : LAN RJ45 Connector PIN NO. DESCRIPTION PIN NO. -
Page 24: Ultra-2/3 68Pin Scsi Connectors
3.18 Ultra-160 68pin SCSI Connector Two 68pin SCSI connectors are described as below. • CN24: Port A, CN25: Port B CN24/CN25 : SCSI pin assignment PIN NO. DESCRIPTION PIN NO. DESCRIPTION +SD12 -SD12 +SD13 -SD13 +SD14 -SD14 +SD15 -SD15 +SDP1 -SDP1 +SD0 -SD0... -
Page 25: Bios Setup
BIOS Setup 4.1 Introduction This chapter discusses the Setup program built into the BIOS. The Setup program allows users to configure the system. This configuration is then stored in battery-backed CMOS RAM so that it retains the Setup information while the power is off. 4.2 Starting Setup The BIOS is immediately active when you turn on the computer. -
Page 26: Using Setup
4.3 Using Setup In general, you can use the arrow keys to highlight items, press <Enter> to select, use the PageUp and PageDown keys to change entries, press <F1> for help and press <Esc> to quit. The following table provides more details about how to navigate in the Setup program using the keyboard. -
Page 27: Main Menu
4.4 Main Menu Once you enter the AwardBIOS™ CMOS Setup Utility, the Main Menu will appear on the screen. The Main Menu allows you to select from several setup functions and two exit choices. Use the arrow keys to select among the items and press <Enter> to accept and enter the sub-menu. -
Page 28: Setup Items
4.4.1 Setup Items The main menu includes the following main setup categories. Recall that some systems may not include all entries. Standard CMOS Features Use this menu for basic system configuration. See Section 4.5 for the details. Advanced BIOS Features Use this menu to set the Advanced Features available on your system. -
Page 29: Load Optimized Defaults
PC Health Status Use this menu to monitor your hardware. Frequency/Voltage Control Use this menu to specify your settings for frequency/voltage control. See section 4.12 for the details. Load Fail-Safe Defaults Use this menu to load the BIOS default values for the minimal/stable performance for your system to operate. -
Page 30: Standard Cmos Setup
4.5 Standard CMOS Setup The items in Standard CMOS Setup Menu are divided into 10 categories. Each category includes no, one or more than one setup items. Use the arrow keys to highlight the item and then use the <PgUp> or <PgDn> keys to select the value you want in each item. CMOS Setup Utility - Copyright ( C ) 1984-2000 Award Software Standard CMOS Features Date:... -
Page 31: Main Menu Selections
Main Menu Selections Item Options Description Date MM DD YYYY Set the system date. Time HH : MM : SS Set the system time Options are in its sub Press <Enter> to enter Primary Master menu the sub menu of detailed (described in Table 3) options Options are in its sub... -
Page 32: Ide Adapters
IDE Adapters The IDE adapters control the hard disk drive. Use a separate sub menu to configure each hard disk drive. Figure 2 shows the IDE primary master sub menu. CMOS Setup Utility – Copyright © 1984-2000 Award Software IDE Primary Master I DE HDD Auto-Detection Press Enter Item Help... - Page 33 Use the legend keys to navigate through this menu and exit to the main menu. Use Table 3 to configure the hard disk. Item Options Description IDE HDD Auto- Press Enter Press Enter to auto-detect the detection HDD on this channel. If detection is successful, it fills the remaining fields on this menu.
-
Page 34: Advanced Bios Setup
4.6 Advanced BIOS Features This section allows you to configure your system for basic operation. You have the opportunity to select the system’s default speed, boot-up sequence, keyboard operation, shadowing and security. CMOS Setup Utility – Copyright © 1984 – 2000 Award Software Advanced BIOS Features Virus Warning [Disabled]... -
Page 35: Virus Warning
Virus Warning Allows you to choose the VIRUS Warning feature for IDE Hard Disk boot sector protection. If this function is enabled and someone attempt to write data into this area, BIOS will show a warning message on screen and alarm beep. Enabled Activates automatically when the system boots up causing a warning message to appear when anything... -
Page 36: Swap Floppy Drive
Swap Floppy Drive If the system has two floppy drives, you can swap the logical drive name assignments. The choice: Enabled, Disabled. Boot Up Floppy Seek Seeks disk drives during boot up. Disabling speeds boot up. The choice: Enabled, Disabled. Boot Up NumLock Status Select power on state for NumLock. -
Page 37: Security Option
Security Option Select whether the password is required every time the system boots or only when you enter setup. System The system will not boot and access to Setup will be denied if the correct password is not entered at the prompt. -
Page 38: Advanced Chipset Setup
4.7 Advanced Chipset Features CMOS Setup Utility – Copyright © 1984 – 2000 Award Software Advanced Chipset Features DRAM Timing By SPD [Enabled] Item Help DRAM Clock [Host CLK] _______________________ Ø SDRAM Cycle Length Menu Level Bank Interleave [Disabled] Memory Hole [Disabled] P2C/C2P Concurrency [Enabled]... -
Page 39: Dram Clock
DRAM Timing By SPD This item allows you to select the value in this field, depending on whether the board has paged DRAMs or EDO (extended data output) DRAMs. The Choice: Enabled, Disabled. DRAM Clock This item allows you to control the DRAM speed. The Choice: Host Clock, HCLK-33M. -
Page 40: Usb Keyboard Support
USB Keyboard Support Select Enabled if your system contains a Universal Serial Bus (USB) controller and you have a USB keyboard. The Choice: Enabled, Disabled. OnChip Sound This item allows you to control the onboard AC 97 audio The Choice: Auto, Disabled. CPU to PCI Write Buffer When this field is Enabled, writes from the CPU to the PCI bus are buffered, to compensate for the speed differences between the CPU and the PCI bus. -
Page 41: Integrated Peripherals
Memory Parity/ECC Check This item enabled to detect the memory parity and Error Checking & Correcting. The Choice: Enabled,Disabled. 4.8 Integrated Peripherals CMOS Setup Utility – Copyright © 1984 – 2000 Award Software Integrated Peripherals OnChip IDE Channel0 [Enabled] Item Help OnChip IDE Channel1 [Enabled] ____________________... -
Page 42: Ide Prefetch Mode
On-Chip IDE Channel0/1 The chipset contains a PCI IDE interface with support for two IDE channels. Select Enabled to activate the primary IDE interface. Select Disabled to deactivate this interface The choice: Enabled, Disabled. IDE Prefetch Mode The onboard IDE drive interfaces supports IDE prefetching for faster drive accesses. -
Page 43: Onboard Fdc Controller
Onboard FDC Controller Select Enabled if your system has a floppy disk controller (FDC) installed on the system board and you wish to use it. If you install and- in FDC or the system has no floppy drive, select Disabled in this field. The choice: Enabled, Disabled. - Page 44 Parallel Port EPP Type elect EPP port type 1.7 or 1.9. The choice: EPP1.7, EPP1.9 Onboard Legacy Audio This field controls the onboard legacy audio. The choice: Enabled, Disabled. Sound Blaster Sound Blaster support. The choice: Enabled, Disabled SB I/O Base Address This item allows you to determine Sound Blaster I/O address setting.
-
Page 45: Power Management Setup
4.9 Power Management Setup The Power Management Setup allows you to configure you system to most effectively save energy while operating in a manner consistent with your own style of computer use. CMOS Setup Utility – Copyright © 1984 – 2000 Award Software Power Management Setup ACPI function [Disabled]... -
Page 46: Pm Control By Apm
1. HDD Power Down : When enabled and after the set time of system inactivity, the hard disk drive will be powered down while all other devices remain active. 2. Doze Mode: When enabled and after the set time of system inactivity, the CPU clock will run at slower speed while all other devices still operate at full speed. -
Page 47: Video Off Method
Video Off Method This determines the manner in which the monitor is blanked. This selection will cause the system to turn off the V/H SYNC+Blank vertical and horizontal synchronization ports and write blanks to the video buffer. Blank Screen This option only writes blanks to the video buffer. -
Page 48: Rtc Alarm Resume
HDD & FDD When On of HDD & FDD, any activity from one of the listed system peripheral devices wakes up the system PCI Master When On of PCI Master, any activity from one of the listed system peripheral devices wakes up the system. Wake Up On LAN/Ring An input signal on the serial Ring Indicator (RI) line (in other words, an incoming call on the modem) and LAN WOL awakens the system from a soft... -
Page 49: Pnp/Pci Configuration Setup
4.10 PnP/PCI Configuration Setup This section describes configuring the PCI bus system. PCI, or Personal Computer Interconnect, is a system which allows I/O devices to operate at speeds nearing the speed the CPU itself uses when communicating with its own special components. This section covers some very technical items and it is strongly recommended that only experienced users should make any changes to the default settings. -
Page 50: Resource Controlled By
Resource controlled by The Award Plug and Play BIOS has the capacity to automatically configure all of the boot and Plug and Play compatible devices. However, this capability means absolutely nothing unless you are using a Plug and Play operating system such as Windows®95. If you set this field to “manual”... -
Page 51: Pc Health Status
4.11 PC Health Status CMOS Setup Utility – Copyright © 1984-2000 Award Software PC Health Status Item Help Current CPU1 Temp. 46℃ ------------------------- Current CPU2 Temp. 48℃ Ø Menu Level Current CPUFAN1 Speed 5336RPM Current CPUFAN2 Speed 5353RPM CPU1 V-Core 1.75V CPU2 V-Core 1.73V... -
Page 52: Frequency/Voltage Control
4.12 Frequency/Voltage Control CMOS Setup Utility – Copyright © 1984-2000 Award Software Frequency/Voltage Control Auto Detect DIMM/PCI Clk [Enabled] Item Help CPU Clock/Spread Spectrum [Default] ------------------------- Ø Menu Level ↑↓←→ Move Enter: Select +/-/PU/PD: Value F10:Save ESC: Exit F1:General Help F5:Previous Values F6:Fail-safe defaults F7:Optimized Defaults... -
Page 53: Defaults Menu
4.13 Defaults Menu Selecting “Defaults” from the main menu shows you two options which are described below Load Fail-Safe Defaults When you press <Enter> on this item you get a confirmation dialog box with a message similar to: Load Fail-Safe Defaults (Y/N) ? N Pressing ‘Y’... -
Page 54: Supervisor/User Password Setting
4.14 Supervisor/User Password Setting You can set either supervisor or user password, or both of then. The differences between are: supervisor password : can enter and change the options of the setup menus. user password just can only enter but do not have the right to change the options of the setup menus. -
Page 55: Exit Selecting
entry to Setup. If set to “Setup”, prompting only occurs when trying to enter Setup. 4.15 Exit Selecting Save & Exit Setup Pressing <Enter> on this item asks for confirmation: Save to CMOS and EXIT (Y/N)? Y Pressing “Y” stores the selections made in the menus in CMOS –... -
Page 56: Appendix A. Watchdog Timer
Appendix A. Watch-Dog Timer The WatchDog Timer is a device to ensure that standalone systems can always recover from abnormal conditions that cause the system to crash. These conditions may result from an external EMI or a software bug. When the system stops working, hardware on the board will perform hardware reset (cold boot) to bring the system back to a known state. - Page 57 Example assembly program: TIMER_PORT = 443H TIMER_START = 443H TIMER_STOP = 843H ;;Initial Timer Counter MOV DX, TIMER_PORT MOV AL, 8 ;;8 seconds OUT DX, AL MOV DX, TIMER_START IN AL, DX. ;;Start counter W_LOOP: MOV DX, TIMER_STOP IN AL, DX MOV DX, TIMER_START IN AL, DX ;;Restart counter...
-
Page 58: Appendix B. E 2 Key™ Function
Appendix B. E Key™ Function The ROCKY-3732EVS provides an outstanding E KEY™ function for system integrator. Based on the E KEY™, you can free to store the ID Code, Password or Critical Data in the 1Kbit EEPROM. Because the EEPROM is nonvolatile memory, you don’t have to worry for losing very important data. -
Page 59: Appendix C. Address Mapping
Appendix C. Address Mapping IO Address Map I/O address Range Description 000-01F DMA Controller #1 020-021 Interrupt Controller #1, Master 040-05F 8254 timer 060-06F 8042 (Keyboard Controller) 070-07F Real time Clock, NMI Mask 080-09F DMA Page Register 0A0-0BF Interrupt Controller #2 0C0-0DF DMA Controller #2 Clear Math Coprocessor Busy... -
Page 60: Dma Channel Assignments
1st MB Memory Address Map Memory address Description 00000-9FFFF System memory A0000-BFFFF VGA buffer C0000-C7FFF VGA BIOS C8000-CBFFF SCSI F0000-FFFFF System BIOS 1000000- Extend BIOS *Default setting IRQ Mapping Table IRQ0 System Timer IRQ8 RTC clock IRQ1 Keyboard IRQ9 Available IRQ2 Cascade to IRQ Controller IRQ10... -
Page 61: Appendix D. Atx Power Supply
ATX power supply but has two types of power switch connection: 2.1. ROCKY-3732EVS (through Power Button & GND): Connect the ATX power button switch to the pin 1 (power button) and pin 2 (+5VSB) of CN26 on the board. And connect the power cable from CN4 of backplane to CN27 of CPU card. - Page 62 B. For the backplanes with ATX power supply connector For some SBC without ATX power ON/OFF function, then you can control the ATX power supply through backplane’s PS ON connector. Refer to the figure below: for the backplanes with ATX connector, the connection can be made simply as following: Connect the ON/OFF (ordinary one) switch to Pin 2 (PS ON) and Pin 3 (GND) of connector CN2...
-
Page 63: Appendix E. How To Used Wake Up Function
Appendix E. How to use Wake-Up Function The ROCKY-3732EVS provides two kind of Wake Up Function. This page describes how to use Modem Wake-Up and LAN Wake-Up function. Wake-Up function is working while you use ATX power supply, Wake-Up By Modem Ring On: You must set the option Wake Up On LAN/Ring of CMOS SETUP to be enabled. -
Page 64: Appendix F. Dimensions
Appendix F. Dimensions...
