Maintenance; Lubrication - MyBinding Standard APC45 Programmable Instruction Manual

This chapter explains the lubrication procedures necessary to keep
the machine in good condition.
6-1 Lubrication (Front Side)
Turn on the power switch.
Stop the knife at the bottom.
- Press the cutting buttons and release them
just before the knife reaches the lower limit.
The knife and clamp lower and stop.
Turn off the power switch.
WARNING
Make sure to turn off the power switch
before the following steps. Otherwise, mov-
ing parts can cause severe personal injury.
Remove the knife cover.

6. Maintenance

Knife Cover
Lubricate using a grease spray.
Lubricate the following parts once every
month.
1. Clamp Screw
2. Knife Guide
3. Clamp Guide
Lubricate also the left side on the items 2.
and 3.
m p
C l a
e r
o l d
r H
t t e
C u
Attach the knife cover.
Turn on the power switch.
Lift the knife.
- Press the cutting buttons to lift the knife.
Move the knife up and down several
times to spread the lubricated grease.
43
