3-4 Function Cutting
Perform the cutting operation of the
step 1.
- Press both cutting buttons.
- When the step 1 is completed, the backgauge
moves to the position of the step 2.
- Press both cutting buttons at the
same time. If they are not pressed
within 0.5 seconds, the machine does
not operate.
- If your hand is released from one of
the cutting buttons while the knife is
lowering toward the lower limit, the
knife stops at that position.
- Release your hands from the cutting
buttons when the cutting operation is
completed. The secondary cutting
operation dose not start even if press-
ing them continuously after the cut-
ting process.
Perform the cutting operation of the
step 2.
- Place and align the sheets to the backgauge
and side guide.
- Check that the following message appears on
the guide window, and press both cutting but-
tons.
- When the step 2 is completed, the backgauge
moves to the position of the step 3. (If the
backgauge moves backward, it pushes out
the sheets first and moves backward.)
Guide Window
M 3
2:296.0
Current Step
2 / 3
3:295.0
Next Step
Repeat the cutting operation in the
same way.
Perform the cutting operation of the
last step.
- Place and align the sheets to the backgauge
and side guide.
- Check that the following message appears on
the guide window, and press both cutting but-
tons.
- When the step 3 is completed, the backgauge
moves to the position of the step 1.
Guide Window
M 3 3 / 3
3:295.0
Last Step
If nothing appears here, the
backgauge moves to the
position of the step 1.
