5-1 An Error Message Appears

Error Message
E01: KNIFE HOME ERROR
E02: CLAMP HOME ERROR
E03: BACKGAUGE ERROR
E04: BACKGAUGE ERROR
E05: BACKGAUGE ERROR
E06: BACKGAUGE ERROR
E14: COVER OPEN
E09: OUT OF RANGE
E10: MEMORY ERROR
PRESS CUTTER BUTTONS

5. Troubleshooting

Cause
The knife is not at the upper limit
when the power switch is turned
on. (The power switch is turned off
while the knife is lowered.)
The clamp is not at the upper limit
when the power switch is turned
on. (The knife is at the upper limit.)
The problem of the home position-
ing switch.
The limit switch is activated.
The encoder malfunctions. The
spindle of the backgauge does not
turn.
The spindle is turned by hand.
The machine is influenced by
noise.
The lower cover is open.
The cutting length out of range is
input.
The program is not recalled cor-
rrectly.
The mechanical problem of the
clamp occurs:
The upper limit sensor and pulse
sensor malfunction.
Remedy
Press one of the cutting buttons,
and while this is pressed, press
another cutting button after 0.5
seconds or later.
Ent
Press the key.
Check the home positioning
switch.
Move the backgauge using the
or button.
Call your local dealer.
Turn off the power switch and on
again.
If this occurs frequently, call your
local dealer.
Close the lower cover.
Ent
Press the key and input the
cutting length within the range.
Ent
Press the key. However,
the data of the EEPROM may be
collapsed. If this occurs fre-
quently, replace the EEPROM.
Remove the cause and press the
cutting buttons.
