3-6 Creating a Cutting Program (Input)
When repeating a complicated cutting job,
it is helpful to create and save the process
to a cutting program. (Up to thirty pro-
grams can be saved.)
This section explains how to create or cor-
rect the cutting programs.
WARNING
This machine must be operated by just one
person at a time.
CAUTION
Do not cut anything besides paper. This
may damage the machine.
[Creating a New Program]
Press the
- The LED on the upper left of the program
memory button is illuminated and shows that
the "program memory" is selected.
- "SELECT COURSE (1-30)" appears in the
guide window.
LED
SELECT COURSE ( 1-30 )
button.
The course
number can
1
be input.
Input the course number for saving
the program.
- For example, this procedure explains how to
save a new program into the course number 14.
1 4
- Press the
numeric keypad. The guide window will be
ready to input the cutting length value for the
step 1.
When the course number 14 is
input,
COURSE14 1 / 0
1: 0
The job name of the course number
should be written down when program-
ming.
To check the process of the course,
press the button.
Ent
keys on the
The value for
the step 1 is
ready to be
input.
23
