5. Pull label roll leading edge forward through the media guide bar, media sensor and place the label
leading edge onto the platen roller.
Media sensor
Media guide bar
6. Adjust the label guide to fit the width of the
label. Make sure the media sensor triangle
indicator is on the paper feed path that can
sense the gap or black or notch for label
registration.
Media sensor indicator
Label guide
7. Close the print head mechanism. Make sure
the latches are engaged securely.
19
Media supply
spindle
