2. Connector

2.1 Daughter board extension connector CN1,2,3 and CN4

Four male headers CN1,2,3 and CN4 can be used to connect with daughter board or
standard wrapping board to STM3220F-EVAL evaluation board. All total
available on it.
Each pin on CN1,2,3 and CN4 can be used by a daughter board after disconnecting it from
the corresponding function block on STM3220F-EVAL evaluation board. Please refer to
17 to table 20 for detail.
Table 17 Daughter board extension connector CN1
Pin Description
1 GND
3 PE3
5 PE5
7 PI8
9 PC14
11 PC15
13 PI10
15 PF0
17 PF2
19 GND
21 PF5
23 PF7
25 PF9
27 PH0
29 PC0
31 PC1
33 PC3
35 PA0
37 PA2
39 GND
41 PH4
43 NC
45 NC
47 EMU_3V3
49 EMU_5V
2 PE2
4 PE4
6 PE6
8 PC13
10 GND
12 PI9
14 PI11
16 PF1
18 PF3
20 PF4
22 PF6
24 PF8
26 PF10
28 PH1
Qing SHAO
Alternative How to disconnect with function block
Function on STM3220F-EVAL board
- -
Trace_D0 -
Trace_D2
IDD_CNT_EN -
OSC32_IN SB4 open
OSC32_OUT SB5 open
MII_RX_ER Remove RS3
FSMC_A0 -
FSMC_A2 -
- -
FSMC_A5 -
SmartCard_RS JP3 open
T &MC
IDD_Measure Remove R82
ment & MC Disconnect Motor Control board from CN5
OSC_IN SB6 open
ULPI_STP -
MII_MDC -
MII_TX_CLK Remove RS5
WakeUP Remove R139
MII_MDIO -
- -
ULPI_NXT Can not be used on daughter board
- -
- -
- -
- -
Trace_CLK -
Trace_D1 -
Trace_D3 -
Anti-Tamper Remove R143
- -
LED3 Remove R141
ULPI_DIR Can not be used on daughter board
FSMC_A1 -
FSMC_A3 -
FSMC_A4 -
SmartCard_OF JP20 open
F & MC
MC Disconnect Motor Control board from CN5
MC Disconnect Motor Control board from CN5
OSC_OUT SB7 open
Page 17
STM3220F-EVAL Board
140 GPI/Os are
