Table 6 CAN1 related Jumpers
Jumper Description
CAN1 transceiver is working in standby mode when JP12 is set as shown
to the right:
CAN1 transceiver is working in high-speed mode when JP12 is set as
JP12
shown to the right: (default setting)
CAN1 transceiver is working in slope control mode when JP12 is open.
CAN1 terminal resistor is enabled when JP13 is fitted.
JP13
Default setting: Not fitted
CAN1_TX is connected to PD1 and all peripherals connected to FSMC
(LCD, PSRAM & OneNAND) are disabled when JP14 is closed.
JP14
Default setting: Not fitted
CAN1_RX is connected to PD0 and all peripherals connected to FSMC
(LCD, PSRAM & OneNAND) are disabled when JP15 is closed.
JP15
Default setting: Not fitted
.
Table 7 CAN2 related Jumpers
Jumper Description
CAN2 transceiver is working in standby mode when JP7 is set as shown to
the right:
CAN2 transceiver is working in high-speed mode when JP7 is set as
JP7
shown to the right: (default setting)
CAN2 transceiver is working in slope control mode when JP7 is open.
CAN2 terminal resistor is enabled when JP9 is fitted.
JP9
Default setting: Not fitted
CAN2_TX is connected to PB13 and USB OTG HS is disabled when JP10
is closed. JP10 must be open for USB OTG HS application.
JP10
Default setting: Not fitted
CAN2_RX is connected to PB5 and USB OTG HS is disabled when JP11
is closed. JP11 must be open for USB OTG HS application.
JP11
Default setting: Not fitted
