PFC SYNC PH10 and PH11
PFC PWM PH12
Encoder A PB8
Encoder B PD13

2.3 MicroSD connector CN6

Figure 7 MicroSD connector CN6
Table 22 MicroSD connector CN6
Pin number Description
1 SDIO_D2 (PC11)
2 SDIO_D2 (PC10)
3 SDIO_CMD (PD2)
4 +3V3

2.4 Ethernet RJ45 connector CN7

Figure 8 Ethernet RJ45 connector CN7
Qing SHAO
27 28
29 30
31 32
33 34
Pin
number
5
6
7
8
9
Page 22
STM3220F-EVAL Board
temperature
VDD_Micro
GND
GND
PC9 Encoder
Index
Viewed from front
Description
SDIO_CLK (PC12)
Vss/GND
SDIO_D0 (PC9)
SDIO_D1 (PC8)
MicroSDcard_detect (PH13)
Viewed from front
03/06/2009
