40 PH11
Table 19 Daughter board extension connector CN3
Pin Description
1 GND
3 PI1
5 PH15
7 PH13
9 PC13
11 RESET#
13 PA11
15 PA9
17 PC9
19 EMU_5V
21 PC6
23 PG7
25 PG5
27 PG3
29 PD15
31 PD14
33 PD12
35 PD10
37 PD8
39 GND
41 PB13
43 PH12
45 NC
47 EMU_3V3
49 EMU_5V
2 PI2
4 PI0
6 PH14
8 PA13
10 GND
12 PA12
14 PA10
16 PA8
18 PC8
20 PC7
22 PG8
24 PG6
26 PG4
28 PG2
30 GND
Qing SHAO
Disconnect Motor Control board from CN5
DCMI_D2 &MC Remove camera module from CN15
Disconnect Motor Control board from CN5
Alternative How to disconnect with function block
Function on STM3220F-EVAL board
- -
I2S_CK -
SmartCard_3/5 Disconnect Motor Control board from CN5
V & MC
MicroSDCard_ Remove MicroSD card from CN6
defect & MC Disconnect Motor Control board from CN5
Anti-Tamper Remove R143
Reset button -
OTG_FS_DM Remove R17
VBUS_FS Remove USB cable from CN8
Remove R18
MicroSDCard_ Remove MicroSD card from CN6
D1 & MC Disconnect Motor Control board from CN5
- -
I2S_MCK & JP21 open
SmartCard_IO
SmartCard_CL -
K
FSMC_A15 -
FSMC_A13 -
FSMC_D1 -
FSMC_D0 -
FSMC_A17 -
FSMC_D15 -
FSMC_D13 -
- -
ULPI_D6 & -
CAN2_TX
DCMI_D3 & Remove camera module from CN15
MC Disconnect Motor Control board from CN5
- -
- -
- -
IO_Expandor_I Remove R136
NT
I2S_CMD -
DCMI_D4 & Remove camera module from CN15
MC Disconnect Motor Control board from CN5
TMS/SWDIO -
- -
OTG_FS_DP Remove R19
OTG_FS_ID Remove R21
MCO JP5 open
MicroSDCard_ Remove MicroSD card from CN6
D0 & MC Disconnect Motor Control board from CN5
LED4 Remove R140
LED2 Remove R154
LED1 Remove R155
FSMC_A14 -
FSMC_A12 -
- -
