ST STM3220F-EVAL User Manual page 16

R u n
MC U mo de
0
ID D_C N T_EN (PI8)
Q13= L OW _POW ER _EN
(T1 p in 3)
Q14 = L P_W AK EU P
(PA0)
Q14n = Switch
co ntro l (U 15 p in 4)
The halt mode measurement procedure can be used in Halt mode and slow or fast active Halt
modes if the IDD current do not exceed 60uA else the Run measurement procedure need to
be used up to 60mA.
Qing SHAO
Halt mode IDD measurement timing
H alt
150mS
Page 16
STM3220F-EVAL Board
W ake-up ID D Measu re C lear C N T
300mS
03/06/2009
450mS
