30 GND
32 PC2
34 VREF+
36 PA1
38 PH2
40 PH3
42 PH5
44 NC
46 NC
48 APP_3V3
50 GND
Table 18 Daughter board extension connector CN2
Pin Description
1 GND
3 PA3
5 PA5
7 PA7
9 PC5
11 PB0
13 PB2
15 PF12
17 PF14
19 GND
21 PG1
23 PE8
25 PE10
27 PE12
29 PE14
31 PE15
33 PB11
35 PH7
37 PH9
39 GND
2 APP_VCC
4 PA4
6 PA6
8 PC4
10 GND
12 PB1
14 PF11
16 PF13
18 PF15
20 PG0
22 PE7
24 PE9
26 PE11
28 PE13
30 GND
32 PB10
34 PH6
36 PH8
38 PH10
Qing SHAO
- -
MII_TXD2 & JP23 open
potentiometer
- -
MII_RX_CLK JP6 open
MII_CRS Remove RS3
MII_COL Remove RS3
OTG_FS_Pow Remove R18
erSwitchOn
- -
- -
- -
- -
Alternative How to disconnect with function block
Function on STM3220F-EVAL board
- -
ULPI_D0 -
ULPI_CLK Can not be used on daughter board
MII_RX_DV Remove RS2, JP8 open
MII_RXD1 Remove RS2
ULPI_D1 -
BOOT1 -
FSMC_A6 -
FSMC_A8 -
- -
FSMC_A11 -
FSMC_D5 -
FSMC_D7 -
FSMC_D9 -
FSMC_D11 -
FSMC_D12 -
ULPI_D4 -
MII_RXD3 Remove RS3
DCMI_D0 Remove camera module from CN15
- -
- -
Audio_DAC_O Remove R115
UT
DCMI_PIXCK Remove camera module from CN15
MII_RXD0 Remove RS2
- -
ULPI_D2 -
OTG_FS_Over Remove R15
current
FSMC_A7 -
FSMC_A9 -
FSMC_A10 -
FSMC_D4 -
FSMC_D6 -
FSMC_D8 -
FSMC_D10 -
- -
ULPI_D3 -
MII_RXD2 Remove RS5
DCMI_HSYNC Remove camera module from CN15
& MC Disconnect Motor Control board from CN5
DCMI_D1 &MC Remove camera module from CN15
