— Instructs scale to change the sign of a number. Interpreted as a hyphen when
entered as part of an ID number.
When preceding any register that stores a value, instructs the scale to clear the
stored value from that specific register. (e.g. Pressing the — tare keys will clear
the tare value in memory.)
When preceding the units key, instructs the scale to convert the weighing units
to the factory default (grams).
0-9 Instructs the scale to enter numerical values given for registers such as ID num-
ber, count, tare or average piece weight.
LED
low bat If lit, battery needs to be charged. (Battery option only)
bat charge If lit, battery is installed and is being trickle charged.* (Battery option only)
remote/local If lit, the remote scale base is active. (Remote Scale Option only)
* Depending on the condition of the battery and the line voltage this LED
may turn off when the battery is completely charged.

DISPLAY SYMBOLS

OK Reading shown is stable. Further operations may be performed.
gross Reading shown is gross weight.
apw Reading shown is average piece weight.
accum Reading shown is the amount stored in the accumulator register.
tare Reading shown is the weight stored in the tare register.
PC Reading shown is given in number of pieces.
g Reading shown is given in grams.
oz Reading shown is given in ounces.
lb Reading shown is given in pounds.
t oz Reading shown is given in troy ounces.
dwt Reading shown is given in pennyweights.
c Reading shown is given in carats.
"x" Reading shown is given in user-definable units.
NOTE: "x" units are preset in kilograms.
INT Scale is operating in either a fast or slow fixed integration mode (update rate).
