PROGRAMMING BAUD RATE AND PARITY
The Setra Super Count is capable of interfacing with a wide variety of computer equipment. To set the
baud rate (the rate at which the scale sends information to a computer or printer) and parity, use the
following procedure:
1. Press the — key.
2. Enter 5555.
3. Press the setup/cal key. The display will read "CAL br".
4. Enter the baud rate. Choose either 300, 600, 1200, 2400, 4800, or 9600, depending on the
baud rate required by your printer or computer.
5. Press the setup/cal key. The display will read "P- 012".
6. Enter the desired parity. Choose either no parity (enter 0), odd parity (enter 1), or even parity
(enter 2). If you are unsure, try entering 0 for no parity. If the scale cannot communicate with
your computer, consult the computer's or printer's manual to determine the required baud rate
and parity.
7. Press the setup/cal key.
8. REPEAT STEPS 1-7 TO ENSURE THIS BAUD RATE & PARITY IS RETAINED EVEN AFTER POWER
IS REMOVED FROM THE SCALE.
NOTE: The factory default baud rate setting is 2400 and no parity. The scale will transmit with the
parity selected; however, it does not check the parity it receives.
DISPLAY HYSTERESIS
Display hysteresis can prevent the apparent "jumpiness" of the scale display in the weighing mode
from moving one digit to the next. For example: If the weight is nearly equal to 235.65 grams, the
display may toggle between 235.6 and 235.7. By performing the following procedure the scale can
be setup to prevent changes to the display that are less than 1 displayed increment, providing greater
stability in the weight reading. The display hysteresis may be enabled or disabled by performing the
following procedure:
1. Press the — key.
2. Enter 6666.
3. Press the setup/cal key. The display will read "H - 01".
4. Enter 1 to enable the display hysteresis or enter 0 to disable the display hysteresis.
5. Press the setup/cal key.
NOTE: The display hysteresis does not affect the display in the counting mode.
The factory default display hysteresis setting is enabled (i.e. 1).
