COUNT A BATCH OF WIDGETS AND RECORD THE TRANSACTION
The inspector wants to count the number of widgets in a batch delivered to stock by an operator and
print a record of the transaction.
1. Press the reset key. This will zero the scale and clear the ID, APW and tare registers.
2. Enter the operator's ID number, up to ten characters.
3. Press the id key. The scale will automatically load the accumulated count value into the count
accumulator.
4. Create a valid APW, either by entering the value through the keypad, a bar code scanner, or by
performing the sampling procedure.
5. Place the pieces to be counted on the scale.
6. Press the accum key. The scale will update the count accumulator and then copy the new
accumulator value into the ID-accumulator memory.
7. The scale will display the accumulated count.
8. Press clear to return to the count.
9. Press print to print the information for this batch. (See printer setup below.)
10. Remove the pieces from the scale.
PRINTER SETUP FOR THIS EXAMPLE
The inspector wants to print a record with the following format:
ID#:
145 pc
This format can be achieved using the ScriptCoder feature. The code sequence is:
ID#:
Codes: 73 68 35 58 32 128 32 32 32 32 32 154 13 10
145 pc
Codes: 143 112 99 32 32 32 32 32 32 65 67 67 32 144 112 99 13 10
If using the ScriptCoder program, the count accumulator and weight accumulator selections in Ap-
pendix XI can be used for the scale output. The count accumulated number of entries and weight
accumulated number of entries cannot be used when printing multiple accumulators by ID.
24
1234 10:27 am
ACC 1210 pc
1234 10:27 am
ACC 1210 pc
