Weighing Platform
Display
Keypad
Level Bubble
Display
Keypad
FIGURE 1. Components and features of the Setra Super Count.
2
Rectangular weighing platform shown is
used on scales of 27 pound capacity
or more.
Adjustable Foot
Weighing Platform
Level Bubble
RS-232C
Interface
Adjustable Foot
Connector
Round weighing platform shown is
used on scales of 5000 gram
capacity or less.
Adjustable Foot
Battery
On/Off Switch
(Optional)
DC Connector
Setra Super Count
Remote Scale
Connector
(Optional)
Battery Door
TM
Operator's Manual
