PRINTING OUT INFORMATION

The Super Count is designed to print out requested or stored information regarding a given batch
when connected to an optional serial printer (see Appendix I). The default RS-232 output from the
scale is all available fields formatted for a label on a Dymo Setra 300 printer.
1. Connect the printer's AC adaptor to a 110-volt outlet.
2. Connect the other end of the adaptor to the printer.
3. Connect the 6 pin telephone jack end of the printer connection cord to the printer's "Input"
port.
4. Connect the male RJ45 end of the connection cord to the scale's female RJ45 port.
5. Perform the necessary counting or weighing procedures on the scale.
6. Press the print key on the scale.
7. Repeat Steps 5 through 6 any time you wish to print out information.
NOTE: a. The print output can be changed for either printing on receipt paper or another label
format on the Dymo Setra 300 printer. Refer to the Print Format in the Setup
Functions.
b. When using a printer other than the Dymo Setra 300, reset the print format and match
baud rate and parity of your scale to the match the printer(see Setup
Functions).
