6. Remove pieces until the display reads the number of pieces you wish to count out or kit.
7. Press the zero key.
8. Repeat Steps 6 and 7 as many times as needed.
NOTE: a. If the average piece weight is known, you may press the — key, enter the average piece
weight, and press the apw key in place of Steps 2-5.
b. If the sample size is not large enough to satisfy the minimum accuracy requirement the
display will read "SUb nnn.PC". Remove the specified number of pieces (i.e. nnn) from
the container, then press the count key.
c. It is possible that the required sample size is larger than the quantity needed for each kit.
For instance, the required sample size is 100 pieces but only 50 pieces are to be kitted
together. In this case follow steps 1 through 5 above, then proceed as follows: place the
100 piece sample back into the container and press the zero key. Continue with steps 6
through 8 above.
ACCUMULATING RESULTS BY WEIGHT OR COUNT
It is sometimes necessary to accumulate weights or counts of various batches; e.g., the number of
capacitors counted or the total weight of fasteners weighed out during a day. The scale can be used
to simultaneously accumulate both weights and counts.
To accumulate a weight, use the following procedure:
1. Enter the weighing mode by pressing the reset key or the clear and zero keys (if in the count-
ing mode).
2. To begin accumulating weights, clear the weight accumulator by pressing 0 accum while in
the weighing mode.
3. Place the object to be weighed on the pan.
4. Press the accum key. This weight is then added into the accumulator. The total accumulated
weight is then displayed.
5. Press the clear key. The current weight is displayed.
6. Repeat steps 3-5 anytime you wish to accumulate the weights of further measurements.
7. Press the display accum keys. The scale now reads the accumulated weight.
NOTE: The clear key must be pressed after completing each accumulation.
To accumulate a count (or reverse count, if kitting), use the following procedure:
1. Press the zero key.
2. Press the sample size key. The scale will display "Add 10. PC". (To increase the sample size,
continue to press the sample size key until the scale displays the desired number.)
