Upgrading The Computer
6
Figure 6 - 8
HDD Bay Cover
Replacement
6 - 12 Upgrading the Hard Disk Drive(s)

Replacing the Hard Disk Drive Bay Cover

1. Reinsert the HDD bay cover by placing it on the bottom case assembly and sliding
it on to the case.
2. Make sure the case markers
3. Slide the cover in the direction of arrow
4. Replace screw
3
1
line up before sliding any further.
1
.
2
3
2
