Modwheel Destination
Modwheel Destination Controls
Start
Cutoff
LFO Depth
Pan
4.3

Loading an Instrument Plug-in

To load a Plug-in Instrument we must be at the Sound level, where there are four Module slots
available. Module slot 1 can host either source Modules or effect Modules. Module slots 2, 3
and 4 can host effect Modules only (of course you can put an effect Module behind a source
Module and add them in series) but more on using effects in the next chapter. For now, lets
load an instrument plug-in to a Sound slot:
Hardware
1. Press the CONTROL button to enter the Control mode.
2. Press the pad you want to load the instrument to.
3. Press Button 3 to put the focus on the SOUND tab.
4. Make sure MODULES is activated to show Module slots 1 to 4 (Button 4).
5. Press Button 5 to select slot 1.
6. Press SHIFT + BROWSE to select the sound source. On the left display, change the TYPE
to PLUG-IN using Knob 1.
Here you can determine how incoming MIDI Modulation Wheel data affects
the Start parameter on page 2.
This allows you to modulate the
types LP2, BP2, HP2 (on page 3) using the MIDI Modulation Wheel.
Here you can adjust the effect of the MIDI Modulation Wheel data on the
LFO Depth of the LFO on page 5.
Another modulation target for the MIDI Modulation Wheel: the panorama
position on Output Parameter page 1.
Cutoff parameter of the Filters with filter
