The Filter on the software.
Screen Element
Type
Mode
Freq
Cut
Res
Modulation
Amount
Source
Envelope Decay
Smooth
Shape
LFO Sync Speed
Shape
Phase
Description
Here you can select between four different filter-types: Notch,
pass), BP (bandpass), and
following parameters vary as indicated.
Cut stands for Cutoff Frequency and is available with all filter-types.
Res controls the amount of Resonance - the amount of amplification
around the cutoff frequency. It is not available with filter-type Notch.
This defines how much the Filter gets modulated by the modulation
source. This can be applied to increase or decrease the cutoff by the mod-
ulation source.
Here you can select between three different modulation sources: Envelope,
LFO Sync and LFO. Depending on your choice for the modulation source,
the following parameters appear to the right:
With Decay you adjust how fast the envelope fades out.
Smooths the shape of the envelope.
Change the shape of the envelope here.
Defines the speed of the modulation in musical values from 16/1 (once ev-
ery 16 bars) up to 1/32 note.
Change the shape of the LFO waveform here.
Adjusts the start phase of the LFO.
LP (lowpass). Depending on the filter type, the
The Effects Overview
Filtering
HP (high-
