Intermec EasyCoder 501 E Installation & Operation Manual page 76

Setup Mode Overview, Part 2
SETUP:
SERVICE
SETUP: SERVICE:
PASSWD: MEDIA SIZE
Enter password:
1138
SERVICE:
MEDIA TYPE
SERVICE:
PRINT DEFS
SERVICE:
PERFORMANCE
SERVICE:
MEMORY ALLOC
Intermec EasyCoder 501 E – Installation & Operation Ed. 1
MEDIA SIZE: XSTART:
XSTART [0]:
MEDIA SIZE: WIDTH:
WIDTH [832]:
MEDIA SIZE: LENGTH:
LENGTH [1200]:
Ent er
MEDIA TYPE:
LABEL (w GAPS)
TICKET (w MARK)
TICKET (w GAPS)
FIX LENGTH STRIP
VAR LENGTH STRIP
PRINT DEFS: HEAD RESIST:
HEAD RESIST [nnn]: Measured
PRINT DEFS: PAPER TYPE:
PAPER TYPE (designation)
(designation)
(designation)
PRINT DEFS: NEW SUPPLIES:
NEW SUPPLIES #
PRINT DEFS: <PRINT> = PRINT
TESTPRINT <C>
Ent er
PERFORMANCE:
NORMAL
HIGH
ULTRA HIGH
MEMORY ALLOC: IMAGE BUFF SIZE:
IMAGE BUFF SIZE [48Kb]:
MEMORY ALLOC: REC BUF UART1:
REC BUF UART1 [300]:
MEMORY ALLOC: TRANS BUF UART1:
TRANS BUF UART1 [300]:
MEMORY ALLOC: REC BUF UART2:
REC BUF UART2 [300]:
MEMORY ALLOC: TRANS BUF UART2:
TRANS BUF UART2 [300]:
MEMORY ALLOC: REC BUF UART3:
REC BUF UART3 [300]:
MEMORY ALLOC: TRANS BUF UART3:
TRANS BUF UART3 [300]:
Ent er
Intermec Fingerprint v6.14
Value is read-only
Printhead resistance is set automatically at start-up.
Depending on model, various paper type
designations are displayed. New setup options
can be added using the "New Supplies" menu,
see below.
Enter the 13-digit code number of the new
supply).
A series of test labels is printed in a loop.
If printer is unable to print a test label, press F5
= EXIT
for a status report.
These menus are only displayed if an optional
interface board with at least one serial
communication channel is installed.
• Press F4 to return to the "Detection" menu in part 1.
• Press F5 key to return to "Media Size" menu.
• Press Setup to exit the Setup Mode.
Chapter 8 Setup Mode
75
